Installation Instructions; Technical Specifications - Altronix Pace1PRMT Installation Manual

Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and
with all local codes and authorities having jurisdiction. Wiring should be UL Listed and/or
Recognized wire suitable for the application.
Pace1PTM and Pace1PRM are not intended to be connected to outside plant leads and should be
installed indoors within the protected premises. Pace1PRM and Pace1PTM are intended for indoor
use only.
1. Pace1PRM installation:
a. Secure unit to desired mounting surface with a proper fastening device utilizing the unit's
mounting hole (Fig. 2a, pg. 3). Unit should be mounted in proximity to ethernet
switch/network, NVR or video server.
b. Connect structured cable from ethernet midspan or endspan device to RJ45 jack marked
[PoE Input] (Fig. 2, pg. 3).
c. CAT5e or higher: Connect CAT5e or higher to connector marked [RJ45 Link] (Fig. 2, pg. 3).
UTP: Connect UTP to connector marked [UTP Link] (Fig. 2, pg. 3).
2. Pace1PTM installation:
a. Secure unit to desired mounting surface with a proper fastening device utilizing the case's
mounting hole (Fig. 2a, pg. 3). Unit should be mounted in proximity of camera/device.
b. Connect structured cable from IP camera/device to RJ45 jack marked [PoE Out] (Fig. 2, pg. 3).
c. CAT5e or higher: Connect CAT5e or higher to connector marked [RJ45 Link] (Fig. 2, pg. 3).
UTP: Connect UTP to connector marked [UTP Link] (Fig. 2, pg. 3).
Parameter
Connections
Input power
requirements
Indicators
Environmental
Conditions
Regulatory
Compliance
Weights
(approx.)
- 2 -

Installation Instructions:

Technical Specifications:

Description
RJ45 for ethernet link or single pair UTP.
Midspan or endspan port connected.
PoE compliant to IEEE 802.3af (15W) and
PoE+ compliant to IEEE 802.3at (30W)
Yellow (RJ45 connector):
Green (RJ45 connector):
Green:
Operating Ambient Temperature (UL60950-1):
Pace1PRM:
Pace1PTM: For 15W:
For 25W:
For 30W:
Relative Humidity:
Storage Temperature:
Operating Altitude:
UL/cUL Listed for Information Technology Equipment (UL 60950-1).
CE European Conformity. C-Tick compliant.
Product: 3.88 oz. (0.11 kg) | Shipping: 6.70 oz. (0.19 kg)
On - Link, Off - No Link, Blinking - Activity.
On - 100Base-TX, Off - 10Base-T.
PoE Active.
– 20ºC to 49ºC (– 4ºF to 120.2ºF).
– 40ºC to 75ºC (– 40ºF to 167ºF)
– 40ºC to 70ºC (– 40ºF to 158ºF)
– 40ºC to 60ºC (– 40ºF to 140ºF)
20 to 85%, non-condensing.
– 40ºC to 75ºC (– 40ºF to 167ºF).
– 304.8 to 2,000m.
Pace1PRMT
