Altronix eBridge1STR Installation Manual

eBridge1STR
eBridge1PCRM
eBridge1ST
- EoC Hardened Mini-Transceiver
Altronix eBridge1STR ethernet over coax adapter kit transmits data at 25Mbps and power over
Coax cable in a PoE+ compliant format. eBridge1PCRM is powered by an external midspan or
endspan. eBridge1PCRM receiver passes PoE/PoE+ power over the same coax cable to eBridge1ST
transceiver which, in turn, passes this power to an enabled IP camera/device. These plug and play
units facilitate a cost-effective, simple way to replace legacy analog products with new IP devices
over existing coax up to 500m.
Agency Listings:
• UL/CUL Listed for Information
Technology Equipment (UL 60950-1).
• CE approved.
Input (eBridge1PCRM):
• Powered by midspan or endspan.
PoE compliant to IEEE 802.3af (15W) and
PoE+ compliant to IEEE 802.3at (30W).
Ethernet:
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair CAT5.
• Distance: up to 500m.
• Speed: 10/100BaseT, half/full duplex,
auto negotiation.
PoE compliant to IEEE 802.3af (15W) and
PoE+ compliant to IEEE 802.3at (30W)
delivered to camera by eBridge1ST.
Power provided by eBridge1PCRM to
eBridge1ST by PoE protocol.*
Coax Link:
• Distance: Coax 500m (Maximum Length of
Coax Type vs. Camera Power/PoE Class,
pg. 4) for power delivery.
• Throughput is rated to pass 25Mbps of
data at distances up to 500m.
• Connectivity: BNC, RG-59/U or similar.
LED Indicators:
• Green - PoE ON (by respective RJ45 jack).
• Yellow and Green LED (RJ45) IP Link
status, 10/100Base-T/active.
*See note on Page 3.
- EoC Adapter Kit
- EoC Receiver
Installation Guide
PLUS
Overview:
Features:
Environmental:
• Operating Temperature:
eBridge1PCRM:
-20ºC to 49ºC (-4ºF to 120.2ºF).
eBridge1ST:
For 15W: -40ºC to 75ºC (-40ºF to 167ºF).
For 30W: -40ºC to 65ºC (-40ºF to 149ºF).
• Storage Temperature:
-40ºC to 75ºC (-40ºF to 167ºF).
• Humidity: 20 to 85%, non-condensing.
Functions:
• Auto detection and protection of legacy
non-PoE cameras/devices.
Applications:
• Retrofit digital IP cameras in an analog
CCTV installation.
• Works with IP Megapixel and
non-Megapixel cameras (see note, pg. 2).
• Extend Network link distance in an
industrial environment over 610m.
• Upgrade deployed CCTV Coax to a digital
network in Retail, Casinos, Airports,
Schools, Hospitals, etc.
Mechanical:
• Dimensions (W x L x H approx.):
eBridge1PCRM:
3.5" x 4.375" x 1"
(88.9mm x 111.1mm x 25.4mm)
eBridge1ST:
2.27" x 2.645" x 1.12"
(57.7mm x 67.2mm x 28.4mm).
Rev. 012816
I.T.E. 43KC
