10. Specifications
42

10.6. Technical data

• Mains connection:
• Consumption:
• Mains fuse:
• Permissible ambient temperature during operation:
• Permissible ambient temperature while stored:
• Cabinet (Stand-alone):
• Built-in cabinet:
• Dimensions:
• Weight:
• Installation dimensions:
NOTE! The unit must be supported - do not cover air holes.
PBI-220047-F 01/2008
230 VAC (115 VAC) +/- 10 %, 50-60 Hz
Max. 160 VA, nom. 80 VA.
1 AT at 230 V (3.15 AT at 115 V)
0 to 45°C. Less than 95%RH up to 35°C.
Linear RH reduction by 3%RH/°C between 35°C and
45°C.
-20°C to +45°C. Less than 75%RH
Painted ALU. cover with handles.
ALU. cover with mounting holes and handles.
See next page
MAP Check 9000: Approx. 8.5 kg
Transport box: Approx. 5 kg
Panel hole: 179x236 (HxW mm)
The height corresponds to 4U
Depth: at least 477 mm
The device must be supported.
Vent holes must not be covered.
