10. Specifications

38
10. Specifications

10.1. Sensor

Solid-state ionic conductor with stabilized zirconium oxide electrolyte.
• Temperature:
• Warm-up time:
• Calibration interval:
• Reference gas:
• Sensor response time:
• System response time:
• Calibration:

10.2. Flow system, MAP Check 900X-1 and MAP Check 900X-2

The measuring gas is supplied continuously by means of an electric pump. The flow system
in MAP Check 900X-1 and MAP Check 900X-2 can avaible with or without bypass flow. A
bypass flow will give a faster response time but will consume more gas.
Gas In
0.2 - 1.2
Gas Out
PBI-220047-F 01/2008
Approx. 200 ml/min
l/min
Pump
Fig. 5. Flow diagram, MAP Check 900X-1 and MAP Check 900X-2
1000K (727°C)
20 min., full specification after 40 min.
12 months
Atmospheric air (20.946 % oxygen)
Less than 50 msec.
Less than 10 sec., depending on flow and measuring gas
hose
Atmospheric air 20.946 % + up to four optional calibration
gases
O
2
sensor
By-pass
hose
