3. Connection
10

3.2. MAP Check PFC

• Pump control signal for external pump control (10-32VDC)
• Alarm relay outputs
• System error / Ready relay output
• Current/ voltage outputs (option)
• CAN bus (option)
9
10
2
3
Fan/ Dust filter
Mains voltage
Mains fuse
RS232C port for serial communication with PC, etc.
ST1
ST2
Gas in
Gas out
Regulated gas in
Regulated gas out
ST1 1.2: Pump control signal, 10-32VDC input (for external pump control)
3.4: O
5.6: O
7.8: System error / Ready relay. Max. 48V, 1A
ST2: 1.2: * Reserved for current output (option)
3.4: * Reserved for CAN bus (option)
5.6: * Reserved for 24VDC outlet (option)
* Other connection is marked with text on the back of MAP Check 9000
PBI-220047-F 01/2008
1
REGULATED
GAS:
IN
MAX 6.5 BAR
(From supply)
OUT
(To application)
alarm 1 relay. Max. 48V, 1A
2
alarm 2 relay. Max. 48V, 1A
2
COPYRIGHT ©
MAP Check 9000 - User Manual
MEASURED
GAS:
7 8
(1+, 2-)
(3+, 4-)
(5+, 6-)
4
5
6
PBI-Dansensor A/S
