8. Error indications / Error correction

In MAP Check 900X-1 and MAP Check 9001-4 all error indications are presented as
being a specific error number. They are also presented in MAP Mon for Windows.
In MAP Check 900X-2 errors are indicated by the LED on the front flashing quickly. The error
type can be seen in "MAP Mon for Windows".
The error numbers are grouped in the following way.
Error
numbers
1 - 9
10 - 19
20 - 29
30 - 31
32 - 33
40
50 - 99
Problem
The display fails to show
O values although the
2
pump is running.
The display is not lit
The display flashes
PBI-Dansensor A/S
Description
User error. The value entered is not within the valid range, etc.
When MAP Check 9000 is switched on, all setup values are read from a
FLASH.
Data have been read correctly but contain errors (e.g. outside valid range).
The data in question are reset (lost) and stored in the FLASH. Always check
the data in question in the setup menu.
Hardware error. A reading/writing error has occurred while reading/writing
setup values to the FLASH.
Possible hardware error. Mains supply line failure signal error.
Errors in connection with setting up extra equipment (errors in Pa.3)
Error in calibration
Fatal hardware errors. (Except error No. 54).
Possible Cause
MAP Check 9000 is not
warm. If for instance the
del.
parameter has been
set to 240 sec. by
mistake, 4 min. will pass
before an O
shown
MAP Check 9000 is not
supplied with the correct
voltage
The fuse in MAP Check
9000 is defective
FL.ER
Bent hose
Defective pump
Flow too low
Measuring gas filter
blocked
Incorrect setting of Min.
and Max. flow limits
COPYRIGHT ©
8. Error indications / Error correction
Possible solution
Wait until MAP Check 9000 has
warmed up. If the unit is cold, this
will take 20 min. (less after
relatively short interruptions)
value is
2
Check connections and switches
Replace the fuse (see
specifications)
Straighten the hose or replace it
Replace defective pump
Adjust flow
Inspect / replace measuring gas
filter
Check setting in the setup menu
Er.xx xx
,
