The setup menu SET.
1. Press when
2. Use and
3. Press for three seconds to change the value (please refer to "Setting alarm limits" on
page 13 for entry of values).
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
FLO.L 100
•
FLO.H 350
•
DEL.
•
PA.1 0001
•
PA.2 1000
•
PA.3 0000
•
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
FLO.l
When entering
FLO.l
make higher than
The diagnostics menu DIA.
1. Press when
2. Select the required value by means of
continuous display of the selected value. The value will be shown until
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
EMF. 165.0
•
TPT.1
•
TPT.2
•
OFFS -0.12
•
ti.po 1234
•
ti.ca 678
•
TI.PU 983
•
S.ref 7.65
•
PRG. 5.3
•
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Calibration menu CAL.
See the section concerning calibration.
PBI-Dansensor A/S
SET.
is shown in the display.
to select the required value.
Flow alarm limit. Alarm limit for min. flow in ml/min.
Flow alarm limit. Alarm limit for max. flow in ml/min.
3
Gas flush time in seconds before measurement.
Valid range: 0 to 250.
Setting alarm relays 1 and 2, device status relay and pump.
See"Setting alarm relays, status relay and pump control" on page 16.
Setting output format and three-way valve.
See "Setting O2 output" on page 17.
Setting up various extra equipment.
FLO.H er. 1
and , is presented if an attempt is made to enter values which
FLO.H
.
DIA.
is shown in the display.
Current sensor EMF in mV.
33
Current internal MAP Check 9000 temperature in °C.
0
Current heater temperature difference in °C.
Difference between current temperature and ideal temperature.
Sensor offset. The result of the last offset adjustment in mV.
Hour counter (10 hour increments). Number of hours for which the
MAP Check 9000 has been switched on.
Hour counter (10 hour increments). Number of hours since the last
calibration of the MAP Check 9000.
Hour counter (10 hour increments). Number of hours for which the
pump has been on.
This menu point will only be indicated if the option "Measurement of
the O sensor reference" has been installed. The output value is
2
stating the reference of the O
See "Measurement of the Sensor Reference Value parameter of the
Oxygen Sensor" on page 21.
Installed program version.
