4.9. Setting alarm relays, status relay and pump control

The parameter
the function of the two alarm relays. Digit No. 3 determines the function of the status relay
and the last digit determines the point from which the pump can be controlled.
PA1:
Alarm 1
PBI-220047-F 01/2008
PA.1
is defined in the setup menu. The first two digits (from the left) determine
Status
Pump
Alarm 2
relay
Pump controlled by
0 : Key. Pump controlled by key only
1 : Key/Ext. Pump controlled by key and external input
2 : Ext. Pump controlled by external input only
MAP Check 9000 status relay
0 : System error, inverted
1 : Ready
2 : System error
3 : Ready, inverted
MAP Check 9000 alarm relay 1 & 2
0 : High O concentration alarm, inverted
2
1 : Low O concentration alarm, inverted
2
2 : High O concentration alarm
2
3 : Low O concentration alarm
2
Settings 4, 5, 6 and 7 correspond to 0, 1 ,2 and 3 but the alarm is not displayed
4 : High O concentration alarm, inverted
2
5 : Low O concentration alarm, inverted
2
6 : High O concentration alarm
2
7 : Low O concentration alarm
2
(Open relay switch = System error)
(Closed relay switch = Ready)
(Closed relay switch = System error)
(Open relay switch = Ready)
(Open relay switch = Alarm)
(Open relay switch = Alarm)
(Closed relay switch = Alarm)
(Closed relay switch = Alarm)
(Open relay switch = Alarm)
(Open relay switch = Alarm)
(Closed relay switch = Alarm)
(Closed relay switch = Alarm)
