Ball Valve Type 546, Central Part - GF CONTAIN-IT Plus Instruction Manual

Spare parts list
10.4

Ball Valve Type 546, central part

see chapter Design, Pos. 9
EPDM sealing set:
Dimension Ball valve
d20/50
d25/50
d32/63
d40/75
d50/90
d63/110
FPM sealing set:
Dimension Ball valve
d20/50
d25/50
d32/63
d40/75
d50/90
d63/110
Code Description
161 486 400
Sealing set EPDM consisting of:
161 486 401
161 486 402
161 486 403
161 486 404
161 486 405
Code Description
161 486 410
Sealing set FPM consisting of:
161 486 411
161 486 412
161 486 413
161 486 414
161 486 415
Instruction Manual
- 2 backing seals
- 1 body seal
- 2 face seals
- 2 stem seals
- 2 backing seals
- 1 body seal
- 2 face seals
- 2 stem seals
