Csa Certification - Tecnotion TM3 Series Manual

Certificate of Compliance
Certificate: 70000843
Project: 70032876
Issued to: Tecnotion B.V.
Twentepoort-West 15
7609 RD Almelo
THE NETHERLANDS
The products listed below are eligible to bear the CSA Mark shown
with adjacent indicators 'C' and 'US' for Canada and US or with adjacent
indicator 'US' for US only or without either indicator for Canada only
PRODUCTS
4211 01 MOTORS AND GENERATORS
4211 81 MOTORS AND GENERATORS – Certified to US Standards
Component type, lineair servo motors, Serie TM, TL, TB and TBW, rated 400 Vmax, 3-ph, 8 kHz,
insulation class B.
Max.
Serie Constant Current
TM3 .. TM18 1.5 – 9.3 A
TL6..TL24 2.26 – 18.1 A
TB12 .. TB30 4.1 – 20.5A
TBW18..TBW45 6.5 – 32.2A
Notes:
1. Motors are Certified as component type motors to be assembled in, and as a part of a machine construction,
where the suitability of the combination is to be determined by CSA Group or other NRTL.
2. Motors are provided with connection cables intended to be used in mechanically protected areas of the final
installation, where the suitability of the construction is to be determined by CSA Group or other NRTL.
3. Motors are provided with thermal sensors to be connected in external ELV-circuits.
DQD 507 Rev. 2012-05-22
©2015 Tecnotion BV - All rights reserved - The contents of this document are subject to change without prior notice.
APPENDIX E
Master Contract: 206865
Date Issued: October 15, 2015
D. Schulz
Issued by: D. Schulz
Max.
Constant Force Cooling Method
60 – 360 N Natural
200 – 800 N Natural
760 – 1900 N Natural
1200 – 3000 N Natural/Water
FF0002
Page 1

CSA Certification

Certificate:
70000843
Project: 70032876
4. The motors need to be mounted on surfaces (heat sink) which provide cooling as per manufacturer's
specifications.
5. Type TBW.. (water cooled) shall have a min. water flow (l/min) at max. temperature (°C) as per
manufacturer's specifications.
APPLICABLE REQUIREMENTS
CAN/CSA C22.2 No. 0 - General Requirements
CAN/CSA C22.2 No. 0.4 - Bonding of Electrical Equipment (Protective Bonding)
CAN/CSA C22.2 No. 100 - Motors and Generators
UL 1004-1 - Rotating Electric Machines – General Requirements
DQD 507 Rev. 2012-05-22
AP E
Tecnotion | www.tecnotion.com | sales@tecnotion.com
Master Contract: 206865
Date Issued: October 15, 2015
Page 2
