Package Weight - Tecnotion TM3 Series Manual

Series Article
TM Coil unit TM 3 FLEX
TM Coil unit TM 6 FLEX
TM Coil unit TM 12 FLEX
TM Coil unit TM 18N FLEX
TM Coil unit TM 18S FLEX
TM Coil unit TM 6 Z FLEX
TM Magnet plate TM 96 mm
TM Magnet plate TM 144 mm
TM Magnet plate TM 384 mm
TM Analog Hall module T
TM Digital Hall module ironcore
24mm
TL Coil unit TL 6N
TL Coil unit TL 6S
TL Coil unit TL 9N
TL Coil unit TL 9S
TL Coil unit TL 12N
TL Coil unit TL 12S
TL Coil unit TL 15N
TL Coil unit TL 15S
TL Coil unit TL 18N
TL Coil unit TL 18S
TL Coil unit TL 24N
TL Coil unit TL 24S
TL Magnet plate TL 192 mm
TL Magnet plate TL 288 mm
©2015 Tecnotion BV - All rights reserved - The contents of this document are subject to change without prior notice.
APPENDIX D
Art. Code Package weight [kg]
4022 368 5075 1.54
4022 368 5076 1.9
4022 368 5078 2.6
4022 368 5500 3.5
4022 368 5519 3.5
4022 368 5300 1.9
4022 368 5225 0.28
4022 368 5226 0.4
4022 368 5227 1.08
4022 368 5139 0.34
4022 368 5418 0.18
4022 369 7458 2.04
4022 368 5032 2.04
4022 368 5311 2.62
4022 368 5312 2.62
4022 369 7459 3.2
4022 368 5033 3.2
4022 369 7460 3.88
4022 368 5034 3.88
4022 368 5223 4.5
4022 368 5224 4.5
4022 368 5014 6.08
4022 368 5035 6.08
4022 368 5193 0.94
4022 368 5194 1.4

Package weight

Series Article Art. Code
TL Analog Hall module T 4022 368 5139
TL Digital Hall module 4022 368 5418
ironcore 24mm
TB Coil unit TB 12N 4022 368 5155
TB Coil unit TB 12S 4022 368 5157
TB Coil unit TB 15N 4022 368 5122
TB Coil unit TB 15S 4022 368 5120
TB Coil unit TB 30N 4022 368 5123
TB Coil unit TB 30S 4022 368 5121
TB Magnet plate TB 192 mm 4022 368 5221
TB Magnet plate TB 288 mm 4022 368 5222
TB Analog Hall module T 4022 368 5139
TB Digital Hall module 4022 368 5418
ironcore 24mm
TBW Coil unit TBW 18N 4022 368 5263
TBW Coil unit TBW 18S 4022 368 5264
TBW Coil unit TBW 30N 4022 368 5242
TBW Coil unit TBW 30S 4022 368 5243
TBW Coil unit TBW 45N 4022 368 5244
TBW Coil unit TBW 45S 4022 368 5245
TBW Magnet plate TB 192 mm 4022 368 5221
TBW Magnet plate TB 288 mm 4022 368 5222
TBW Analog Hall module T 4022 368 5139
TBW Digital Hall module 4022 368 5418
ironcore 24mm
AP D

PACKAGE WEIGHT

Tecnotion | www.tecnotion.com | sales@tecnotion.com
Package weight [kg]
0.34
0.18
5.62
5.62
6.62
6.62
12.66
12.66
2.34
3.52
0.34
0.18
8.02
8.02
13.28
13.28
19.12
19.12
2.34
3.52
0.34
0.18
53
