Watercooling - Tecnotion TM3 Series Manual

Nipples
Thread holes
Recommended Nipple/Fitting
Sealings
Tightening torque
* Other 1/8" Push and Pull Fitting can also be applied. The use of smaller hose diameter and /or
nipple diameter can reduce the flow.
Table 3.14: recommendations for TL and TBW water cooling connections.
3.3

Watercooling

Tecnotion TL and TBW series iron core motors come equipped with wa-
ter cooling capabilities. The continuous force water cooled specifications
for the TL and TBW series are based on pure water cooling. This chapter
explains how to design your water cooling system with water and other
common coolants.
Further information regarding the location and dimension of the
water cooling connections can be found in chapter
connections on page 16.
Connection of hoses
When fitting the hoses, the connections have to be free of greases and oil.
The two cooling channels of the TL-motor can be connected in series. Both
cooling channels can also be used in parallel configuration. This connecti-
on reduces the pressure drop, but only if cavitation is less ø6mm-ø8mm,
when using Y-joints.
©2015 Tecnotion BV - All rights reserved - The contents of this document are subject to change without prior notice.
TL-series TBW-series
4 times M5 (on both 2 times 1/8" NPT (both on
sides of coilunit) one side)
M5 nipple Push-Pull Fitting, -Festo
QS-1/8-8*
M5 plastic sealings and Teflon tape
Loctite 638/648 glue
0,2 - 0,3 Nm 4.0 Nm
3.2.9 Water cooling
TL-series
Hose diameter ø4mm (inner diameter)
Minimum flow diameter fitting ø2.5mm
Hose examples: Festo PU-4*
Rauclair PVC E 4x1*
flexible
*Other hoses can also be applied, but the outer diameter should Ø8mm to fit properly on a 1/8"
push and pull fitting.
Table 3.15: Recommended watercooling connections
TL6 TL12 TL15 TL18
Minimum 0.7 1.4 1.8 2.2
Flow (l/min)*
Pressure drop 1 2 2 2
(bar)*
*Values are based on pure water coolant and depend on used connections and hose-system.
Table 3.16: Presure drop value per coil type
CH 3 MOTOR CONFIGURATION
TBW-series
Ø8mm (outer diameter)
Ø5mm
Festo PUN-H-8x1,25*
TL24 TBW18 TBW30 TBW45
2.9 3.1 5.2 7.8
3 1 1.5 2.5
