Tecnotion TM3 Series Manual page 20

Power cable
The power cable can be confectioned by the user to fit the servo drive. All
motors require an extra flexible cable between the coil and the servo drive
except for the TM –series.
Powercable Color code TM/TL/TB/TBW
3-phases L1 black '1'
L2 black '2'
L3 black '3'
Protective Earth green/yellow
Shield Metal shield
Table 3.19: Power cables wire identification
Protective earth
Internally the motor's protective earth wire is galvanically connected to the
motor housing. This wire must be connected to the protective earth con-
nector of the servo amplifier.
Provide the motor system with protective earth lines to the amplifier that
are as short as possible.
Provide the magnet track with an effective protective earth connection.
Temperature sensor cable
The coil unit is equipped with two temperature sensors, one PTC-1k-type
for protection and one of the KTY83-122 type for temperature measure-
ment.
Please refer to chapter 3.5 Temperature sensors on page 21
©2015 Tecnotion BV - All rights reserved - The contents of this document are subject to change without prior notice.
Connection to servo controller
3-phases
Protective Earth
Protective Earth
for more
information regarding the sensors. The temperature cable consists of four
wires. For wire color and function, see table 3.19. Refer to
length per series on page 19 for the length of the temperature sensor
cable.
All motors require an extra flexible temperature sensor cable between the
coil and the servo drive except for the TM-series.
Sensor cable (color) Connection to servo controller
PTC (white) PTC
PTC (brown) PTC
KTY83-122 (green ) KTY83-122
KTY83-122 (yellow) KTY83-122
Shield Protective Earth
Table 3.20: Sensor cable wire identification
CH 3 MOTOR CONFIGURATION
Table 3.17: Cable
