Unlocking the Digitizer

1. Remove the yellow "Unlock" stickers from your digitizer.
2. With the digitizer power off, tilt the digitizer and locate the locking switch at
3. Push the locking switch to the position as indicated in the graphic, with the
4. Raise the digitizer lid (TMA), and look for the locking switch at the base of
5. Push the locking switch to the position as indicated in the graphic, with the
NOTE: To lock the digitizer and the TMA (for shipping and other purposes), turn
the locking switch to the "Locked" position. When locking the digitizer, do not
turn the digitizer upside down when locking the digitizer back.
20 Medi-2200 Plus User's Manual
the bottom left corner of the digitizer. Do not turn the digitizer upside down
when attempting to unlock, as this may damage the digitizer's mechanism.
icon on the lock showing as "unlocked".
the TMA.
icon on the lock showing as "unlocked".
Unlocked
Locked
Locked Unlocked
