Step 3: Unlocking the Digitizer

1. Remove the yellow "Unlock" sticker
2. With the digitizer power off, turn the
3. Using a screwdriver, push and turn
18 MII-800XL Plus User's Manual
from your digitizer.
digitizer on its side and locate the
locking screw at the bottom of the
digitizer.
the locking screw counterclockwise to
the unlock position.
When successfully unlocked, the
screw will push out a little, protruding
slightly from the bottom of the
digitizer.
NOTE: To lock the digitizer (for shipping and other purposes), follow the
steps below:
1. Turn off the digitizer.
2. Turn the digitizer back on.
When the indicators on the front of
your digitizer stop blinking, use a
screwdriver, and then push and
turn the locking screw clockwise to
the locked position.
When the screw has been
tightened, this indicates that your
digitizer is locked.
3. Turn off your digitizer.
Unlocked
Locked
