Scanning Dental Films

ScanWizard Medi is a scanning software designed by Microtek for X-ray films or
reflectives scanning used for a medical purpose. Its user-friendly interface enables
you to easily start the scanning process and finish all the scan jobs. Refer to the
ScanWizard Medi software manual for more details.
1. Follow the procedures for "Positioning
2. Launch ScanWizard Medi (either as a
3. Make sure you are in the "X-Ray" scanning
4. Select your image output type in the Type
5. Select your desired image output resolution in the
6. If necessary, click the Window Expansion button
7. Click the Smart-Scan button on the control panel
28 Medi-2200 Plus User's Manual
Dental Films" to place the film holder and
dental films on the digitizer glass surface.
stand-alone by clicking the program icon,
or by using the "File-Import" or "Scan"
command from an application program).
mode. If not, click the "Scan Material"
icon in the Preview window; then, select
"X-Ray" as your scanning mode.
drop-down menu.
– Select Gray Scale to scan the image
in 8-bit grayscale.
– Select Gray Scale (12-bit) to scan the image in 12-bit grayscale.
– Select Gray Scale (16-bit) to scan the image in 16-bit grayscale.
Resolution drop-down menu. The default setting is
300 dpi for the X-Ray scanning mode.
to reveal the image correction tools to adjust image
quality.
or the buttons on the Medi-2200 Plus unit to start
scanning.
– Press the button on the digitizer if using the Intraoral X-Ray Film
Holder.
– Press the button on the digitizer if using the Panoramic X-Ray Film
Holder.
– Press the button on the digitizer if using the Cephalometric X-Ray Film
Holder.
