Block Diagram - Congatec SMARC conga-SMX8-X User Manual

3

Block Diagram

conga-SMX8-X
SPI NOR
Flash Memory
A35 Console
Transceiver
SCU Debug
Wi-Fi/
Module*
Copyright © 2020 congatec AG
LPDDR4
SDRAM
eMMC 5.1
RTC
JTAG*
RS-232
SER2*
PCIE_A*
SDIO* NXP i.MX 8X
BT
USB4* *
, 4
Applications Processor
USB_SS*¹
PWR I2C
PMIC
DSI-HDMI
Bridge*
PHY
PHY
USB Hub
I2C Expander
* Assembly option
*¹ i.MX 8DualX SoC does not support USB 3.0.
*² HDMI by default on PN: 051105. Not available for industrial variants.
+Vin
*³ i.MX 8DualX SoC only supports 10/100 Mbps on GBE1.
* Wi-Fi/BT by default on PN: 051104 and USB4 therefore not available.
4
SX8Xm01
SMARC 2.0
DP0
I2S2
I2S0
HDMI* *²
,
, *²
LVDS1/DSI1
LVDS0/DSI0
PCIE_A (PCIe Gen3)
PCIE_[B:D]
SATA
GBE0 (GbE)
GBE1 (up to GbE)*³
SDIO
CSI0
CSI1 (4 lanes)
USB0 (USB 2.0 OTG)
USB1 (USB 2.0)
USB2 (USB 3.0/2.0)*¹
USB3 (USB 3.0/2.0)*¹
USB4 (USB 2.0)*⁴
CAN0 (FlexCAN)
CAN1 (FlexCAN)
SER3* (2 wire)
SER0 (4 wire)
SER1 (2 wire)
SER2 (4 wire)
I2C
SPI0
SPI1
GPIO[0:6]
GPIO[7:11]
17/32
