5.2 Camera Inteface (MIPI
The conga-SMX8-X offers CSI1 pins for one MIPI CSI-2 camera with up to four lanes and supports a bitrate of up to 1.5 Gbps per lane.¹
Note
1. The conga-SMX8-X does not offer CSI0 pins.
5.3

SDIO Card (4 bit) Interface

The conga-SMX8-X offers SDIO pins for one SD/SDIO card interface. This interface supports:
• SD/SDIO specification 3.0
• 200 MHz SDR signaling for up to 100 MBps
• Secure Digital eXtended Capacity (SDXC™) cards
• UHS-I @SDR 104/50 and DDR50
• Default Mode and High Speed Mode
5.4

SPI

The conga-SMX8-X offers SPI[0:1] pins for one Serial Peripheral Interface (SPI) via SPI1 pins and one Quad SPI (QSPI) via SPI1 pins.
Note
1. The conga-SMX8-X does not support eSPI.
5.5

Audio (I2S)

The conga-SMX8-X offers I2S0
Note
1. conga-SMX8-X variants with HDMI pins do not offer I2S0 pins. The pin signals are routed to the onboard DSI to HDMI bridge instead to
support audio output via HDMI.
Copyright © 2020 congatec AG
CSI)
®
and I2S2 pins for up to two Inter-IC Sound (I²S) buses.
