6.14. Buttons

6.14.1. External ON-OFF Button (J24)

Table 25: External ON-OFF Button

Pin Function
1 ON-OFF
2 GND

6.14.2. External Reset (J23)

Table 26: External Reset Button

Pin Function
1 RESET#
2 GND
Direction
IN
Ground
Direction
IN
Ground
