Distal Locking
Alternative technique: Measure using depth gauge
Instrument
03.019.017 Depth Gauge for MultiLoc Humeral Nailing
System
The depth gauge can be used for screw length determination.
Assemble the depth gauge with its outer sleeve.
Insert the depth gauge through the protection sleeve. Press
the outer part of the depth gauge firmly to the cortex to
ensure accurate measurement. Read the screw length directly
off the depth gauge.
Note: The blue mark on the depth gauge will align with the
outer opening of the protection sleeve.
