3.5 Mm Locking Screws; Attach Centering Sleeves - Synthes MultiLoc Proximal Humeral Nail Technique Manual

Proximal Locking

3.5 mm Locking Screws

1

Attach centering sleeves

Instruments
03.019.019 Centering Sleeve for 3.5 mm Titanium
Locking Screws, and 4.5 mm Titanium
MultiLoc Screws
03.019.021 5.8 mm/2.8 mm Drill Sleeve, for 03.019.019
Remove the lateral aiming arm.
If not done so previously, attach a centering sleeve to the
MultiLoc screw. Gently tilt the centering sleeve anteriorly
and lock the drill sleeve in the centering sleeve by clicking it
into place.
Ensure the two handles of the drill sleeve are exactly
perpendicular to the nail. Rotate the assembly, if necessary.
26 Synthes MultiLoc Proximal Humeral Nail Technique Guide
