Nail Positioning

1

Assemble lateral aiming arm

Instruments
03.019.008 Aiming Arm, lateral, for MultiLoc Proximal
Humeral Nail
03.019.030 Aiming Arm Knob
Insert the knob into the aiming arm, ensuring that the aim-
ing arm is oriented correctly. Attach the aiming arm to the
insertion handle and tighten the knob.
Note: Ensure the aiming arm shows "RIGHT" if used for the
right humerus and "LEFT" if used for the left humerus.
Optional technique: Assemble anterior aiming arm for
anterior screw (level C) or ascending screw (level E)
Instruments
03.019.009 Aiming Arm, anterior, for MultiLoc Proximal
Humeral Nail
03.019.031 Aiming Arm Knob
If the anterior screw (lesser tuberosity) or the ascending
screw will be used, connect the anterior aiming arm to the
insertion handle and tighten the knob.
