Synthes MultiLoc Proximal Humeral Nail Technique Manual page 45

4.0 mm Titanium Locking Screws
recess
Material
– Titanium-6% aluminium-7% niobium alloy
Drill
3.2 mm
Color
Blue
Dimensions
– 18 mm to 70 mm lengths, in 2 mm increments
– Outer diameter: 4.0 mm
– Core diameter: 3.3 mm
– T25 StarDrive recess
– Fully threaded
– Self-tapping
Length
(mm)
04.005.408 18
04.005.410 20
04.005.412 22
04.005.414 24
04.005.416 26
04.005.418 28
04.005.420 30
04.005.422 32
04.005.424 34
04.005.426 36
04.005.428 38
04.005.430 40
04.005.432 42
04.005.434 44
04.005.436 46
Available nonsterile or sterile-packed. Add "S" to product number for sterile product.
◊
, with T25 StarDrive
◊
Length
(mm)
04.005.438 48
04.005.440 50
04.005.442 52
04.005.444 54
04.005.446 56
04.005.448 58
04.005.450 60
04.005.452 62
04.005.454 64
04.005.456 66
04.005.458 68
04.005.460 70
MultiLoc Proximal Humeral Nail Technique Guide Synthes 43
