Information key

Where is the Information key on the meriGauge Plus?
What does the Information key normally display on the
meriGauge Plus?
User Manual for meriGauge Plus System
Find Quality Products Online at:
9R479-D
The Information key is the red triangle in the Meriam logo.
BATT % displays the percentage on the bar graph and in digits
•
or USB POWER displays.
The type of pressure sensor displays.
•
CAL DATE displays the date that Meriam calibrated the
•
meriSense sensor.
• USL displays the Upper Specification Limit on the sensor.
LSL displays the Lower Specification Limit on the sensor.
•
LT MAX % displays the Life-Time Maximum that has been
•
reached on the sensor.
• The characters SENSOR F/W display first and then they scroll
across the screen from right to left to display VER. with the
version number of the firmware.
The characters SENSOR S/N display first and then they scroll
•
across the screen from right to left to display S/N with the
serial number of the sensor.
The characters SNSR NAME display first and then they scroll
•
across the screen from right to left to display the sensor's
name.
The characters GAUGE F/W VER. display first and then they
•
scroll across the screen from right to left to display VER. with
the version number of the firmware.
The characters GAUGE S/N display first and then they scroll
•
across the screen from right to left to display S/N with the
serial number of the gauge.
The characters GAUGE NAME display first and then they scroll
•
across the screen from right to left to display the gauge's
name.
