Specifications; Approvals - Meriam meriGauge Plus User Manual

Specifications

Approvals

MGP7000X Intrinsically Safe Model
MS700X Intrinsically Safe model
MGP7000 and MS700 (General Purpose models)
User Manual for meriGauge Plus System
Find Quality Products Online at:
9R479-D
ATEX
cULus Listed
Entity parameters:
ATEX
IECEx
cULus Listed
Entity parameters:
GlobalTestSupply
www.
II 1 G; Ex ia IIC T4 Ga
DEMKO 16 ATEX 1809X
Intrinsically Safe, Exia
Class I, Div. 1 Groups A, B, C, D: T4
Class I, Zone 0, AEx ia IIC T4
–10º C < Ta < +50º C
Po = 1.249W, Io = 227mA, Co = 35 μF,
Lo=0 μH, Uo = 5.5VDC
CE Compliance
II 1 G; Ex ia IIC T4 Ga
DEMKO 16 ATEX 1785
Ex ia IIC T4 Ga
–10º C < Ta < +50º C
IECEx UL 16.0120
Intrinsically Safe, Exia
Class I, Div. 1 Groups A, B, C, D: T4
Class I, Zone 0, AEx ia IIC T4
–10º C < Ta < +50º C
Pi = 1.249W, Ii = 227mA, Ci = 30 μF,
Li=0 μH, Ui = 5.5VDC
CE Compliance
CE Compliance
.com
October 2018
30 of 47
