Troubleshooting checklist
The words "NO SENSOR" display on the gauge
User Manual for meriGauge Plus System
Find Quality Products Online at:
9R479-D
Follow these steps to troubleshoot the meriGauge Plus connection
with meriSense sensor when the message NO SENSOR appears:
1. Turn off the meriGauge Plus gauge.
2. Remove the gauge from the sensor.
3. Re-attach the gauge to the sensor.
Remember: The gauge will face the same direction as the Meriam
logo on the sensor. (You may hear it click when it locks in place.)
See the Meriam logo in the red circle in the figure below.
Note: The locking pin prevents the gauge from accidentally
disconnecting from the sensor.
4. Turn on the meriGauge Plus gauge.
GlobalTestSupply
www.
October 2018
46 of 47
