What does the Information key do while DATA LOG
records data?
User Manual for meriGauge Plus System
Find Quality Products Online at:
9R479-D
INTERVAL.
Interval tells you the hours, minutes, or seconds that was
•
selected in Setup tab in meriSuite CG for the data log.
Interval displays dashes "------" when On Demand is the data
•
log type. On Demand has no intervals.
PTS. CFG.
Points Configured tells you the number of points that was
•
selected in Setup tab in meriSuite CG for the data log.
But, Points Configured displays dashes "------" if the gauge was
•
configured for a fixed amount of time.
Additionally, Points Configured displays dashes "------" if the
•
Forever duration was selected.
TIME CFG.
(CFG. MIN, CFG. HR, CFG. DAYS, HR MIN, DAY HR)
Time Configured tells you the duration that was selected in
•
Setup tab in meriSuite CG for the data log.
But, Time Configured displays dashes "------" if the gauge was
•
set to record a specific number of points.
Additionally, Time Configured displays "------" if the Forever
•
duration was selected.
Toggle key
While recording data, the Information key becomes a toggle key.
It toggles between the first notice: Log and point number and the
second notice: days, hours, minutes, and seconds.
• Both notices display the remaining duration of points or time.
When the duration is set for Minutes, Hours, Days, or Points,
•
then the point number counts down to zero.
When the point number reaches zero, the gauge displays
•
--COMPLETED--.
