List of Measurement Units

Measurement units are stored on a sensor
User Manual for meriGauge Plus System
Find Quality Products Online at:
9R479-D
Formats used in the LCD display
Hours, minutes, and seconds in this format:
•
Days, hours, minutes, seconds.
•
When the days, hours, minutes, and seconds reach zero, the
•
gauge displays --COMPLETED--.
Note: When Days or Forever are selected for duration, then three
additional (3) digits display for days up to a maximum of 366 days.
The other six (6) digits display as hours, minutes, and seconds.
• Each meriSense sensor stores a complete list of measurement
units.
The meriSuite CG app gives you the ability to configure
•
specific measurement units to specific sensors.
The meriGauge Plus displays only the units selected in
•
meriSuite CG for individual sensors.
When the meriSense pressure sensors are shipped, the
•
common 12 measurement units are available. These 12 units
appear in bold type in the following Standard Units list.
Standard Units (non-custom)
1. PSI 12. CMW4C
2. INW20C 13. CMW60F
3. INW4C 14. MW20C
4. INW60F 15. MW4C
5. FTW20C 16. MW60F
17. INHG0C
6. FTW4C
7. FTW60F 18. MHG0C
8. MMW20C 19. CMHG0C
9. MMW4C 20. MMHG0C
10. MMW60F 21. TORR
22. KG/CM2
11. CMW20C
GlobalTestSupply
www.
October 2018
HH.MM.SS
DDD HH.MM.SS
23. KG/M2
24. PA
25. HPA
26. KPA
27. MPA
28. BAR
29. MBAR
30. ATM
31. OZ/IN2
32. LB/FT2
