Pressure limits
User Manual for meriGauge Plus System
Find Quality Products Online at:
9R479-D
Operating pressure limits
Do not exceed the pressure limits listed in
•
ranges section for the MS700X meriSense.
Failure to operate within the specified pressure limits could
•
result in injury.
Overrange limit
Overrange pressure means the value is outside the calibrated
upper or lower range.
Up to 110 % of range, meriGauge Plus displays the accurate
•
pressure.
• Above 110 %, it flashes red. This indicates that the applied
pressure exceeds the calibrated range.
Note: If the calibrated pressure range is exceeded,
the pressure displayed may not be accurate
Above 120 %, it flashes red and displays dashes.
•
Burst pressure limit
Burst pressure is the point at which the sensor may mechanically
leak.
Rated Burst Pressure
PSI
5 10 times
15 6 times
30 6 times
50 6 times
100 4 times
300 4 times
500 3 times
1000 3 times
3000 3 times
GlobalTestSupply
www.
October 2018
the sensor pressure
