Data Log Lite and Data Log Pro

View the "BATT %" before you begin
Data Log Lite is limited to one data log
Data Log Pro provides a maximum of 128 logs
Start the data logging process
Stop the data logging process
User Manual for meriGauge Plus System
Find Quality Products Online at:
9R479-D
Data Log Lite runs up to one hour.
Note: Do not start data logging if the outline of the battery icon is
flashing.
Data Log Lite can record and hold only one data log at a time.
Note: When you press and hold the Zero key while DATA LOG
appears in the LCD display, a new data log begins to record over the
existing data log.
Data Log Pro provides a maximum of 128 logs or a maximum of
100 000 data points.
1. Press the Display key until you see DATA LOG appear in the
LCD display.
2. Press and hold the Zero key until you see —STARTING—. The
data log symbol starts to flash indicating it is recording data.
Data Log Lite records data every 15 seconds for one hour.
3. —COMPLETE—appears after one hour.
Note: Auto Off is suspended during data logging. If you selected 5
Minutes for Auto Off, then meriGauge Plus remains on 5 minutes
after data logging completes, and then turns off.
Here are some of the actions that can complete the data logging
process before the one hour:
Press and hold the Zero key until you see —STOPPING—.
•
Press the Power key to turn off the meriGauge Plus.
•
Remove the meriGauge Plus from a sensor.
•
Connect the meriGauge Plus to the meriSuite CG app.
•
The duration was reached that you selected in the Setup tab.
•
