SET COMMUNICATION:

This section define the fundamental communication parameters of two buses, PROFINET and SNMP.
By Pressing the "Set Communication" button from the main window for SW67613 (Fig. 2) the window
"Set Communication" appears (Fig. 3).
The means of the fields for "PROFINET" are:
In the fields "IP ADDRESS" the IP address of PROFINET side of the converter is defined;
In the fields "SUBNET
In the fields "GATEWAY" the default gateway of the network is defined. This feature can be
enabled or disabled pressing the Check Box field. This feature is used for going out of the net;
In the field "Port" the port number used for PROFINET communication is defined (fixed at 34964);
In the field "PROFINET Name of
In the fields "Number Byte
defined;
In the fields "Number Byte
defined.
The means of the fields for the "SNMP" section are:
In the fields "IP ADDRESS" the IP address of SNMP side of the converter is defined;
In the fields "SUBNET
In the fields "GATEWAY" the default gateway of the network is defined. This feature can be
enabled or disabled pressing the Check Box field. This feature is used for going out of the net;
In the field "SNMP Name of
In the field "Contact" the contact for SNMP Agent station is defined;
In the field "Location" the location for SNMP Agent station is defined.
ADFweb.com S.r.l.
Mask" the SubNet Mask of PROFINET side of the converter is defined;
Station" the name of PROFINET side of the converter is defined;
IN" the number of input byte of PROFINET side of the converter is
Out" the number of output byte of PROFINET side of the converter is
Mask" the SubNet Mask of SNMP side of the converter is defined;
Station" the name of SNMP side of the converter is defined;
User Manual PROFINET / SNMP Agent
Document code: MN67613_ENG Revision 1.100
Figure 3: "Set Communication" window
