Each SNMP variable created will have its own OID and it will be created following this rule:
OID 1 (first row of "Set SNMP Access -> SNMP Write" table): .1.3.6.1.4.1.49314.1.1.1.5.9.1
OID 2 (second row of "Set SNMP Access -> SNMP Write" table): .1.3.6.1.4.1.49314.1.1.1.5.9.2
OID X (Xth row of "Set SNMP Access -> SNMP Write" table): .1.3.6.1.4.1.49314.1.1.1.5.9.X
The memory blocks are accessible with these OIDs:
Block1: .1.3.6.1.4.1.49314.1.1.1.5.1.0
Block2: .1.3.6.1.4.1.49314.1.1.1.5.2.0
Block3: .1.3.6.1.4.1.49314.1.1.1.5.3.0
Block4: .1.3.6.1.4.1.49314.1.1.1.5.4.0
Block5: .1.3.6.1.4.1.49314.1.1.1.5.5.0
Block6: .1.3.6.1.4.1.49314.1.1.1.5.6.0
Block7: .1.3.6.1.4.1.49314.1.1.1.5.7.0
Block8: .1.3.6.1.4.1.49314.1.1.1.5.8.0
Note:
The OIDs in writing are readable too with GET command.
