9
BACNET EXPLORER
A typical working example of a BACnet Explorer on a BACnet Network:
BACnet Explorer
BACnet/IP
For additional details related to the BACnet Explorer, go to the Sierra Monitor Resource Center
(www.sierramonitor.com/customer-care/resource-center) and download the BACnet Explorer Start-
up Guide.
For purchasing information, look up the BACnet Explorer page on the Sierra Monitor website
(www.sierramonitor.com/connect/all-protocol-gateway-products/bacnet-explorer) and click on the
"BUY NOW" tab.
PC Connected to
BACnet
Explorer's Web
Browser
Multi-Port Switch
Figure 23: BACnet Explorer on a BACnet Network
Page 26 of 43
Riello ProtoNode Start-up Guide
up to 32 BACnet
MS/TP devices
Modbus RTU
BACnet Router
Modbus RTU
up to 32
BACnet MS/TP
devices
BACnet MS/TP
BACnet/IP
