32 Technical information
32.2 Instrument classifications
234 Planmeca Compact i3
Connection:
Water and air filters
Water filter:
Air filter:
Replacement of water and air filters should be performed by qualified
service technician according to the maintenance schedule.
See section "Annual maintenance" on page 6.
Suction connection
Vacuum:
Flow rate:
Connection:
Type:
Class:
The electrical classification of the instrument is marked on the instrument
hose either as B or BF. If there is no marking, no electricity flows through the
instrument.
Type B
Type BF
The following lists the instruments that are available for the Planmeca dental
unit and their electrical classification type.
Instrument classifications
Instrument
DCI autoclavable 3-way syringe
Luzzani Ergo 3-way syringe
Luzzani Minibright 6-way syringe
Luzzani Minibright 6-way syringe with LED
PM fibre optic turbine hose S
Bien-Air MCX brushless micromotor with LED
Bien-Air MX2 brushless micromotor with LED
Planmeca Minetto brushless micromotor with LED
Morita TORX micromotor
EMS No Pain scaler
EMS No Pain LED scaler
1/4"
25 µm (internal), 5 µm (external suggested)
25 µm (internal)
≥ 150 mbar
≥ 550 l/ min
Ø 50 / 46 mm
Medium volume
Wet
Type
B
B
B
B
B
B
B
B
B
B
B
