From dental unit
21.4.5 Adjusting intensity of operating light in composite mode
User's manual
Hands-free with sensor
Once the operation light is lit, keep your hand longer in front of the sensor to
adjust the intensity of the light.
NOTE
If the operating light is installed to another manufacturer's dental unit, the
intensity adjustment can be done only from the operating light.
The light intensity is displayed on the Operating light button. When you
change the intensity, the information on the button changes accordingly.
Control panel: Press and hold the Operating light button to adjust the
operating light intensity.
Foot control: Push and hold the left-side knob up to adjust the operating light
intensity.
NOTE
The foot control can also be configured so that the intensity is adjusted when
you push and hold the right-side knob up. Contact your Planmeca dealer.
After one second, the intensity will increase until you release the button/
knob. When you press and hold the button/knob again, the intensity will start
to decrease.
The intensity adjustment range is from 30% to 100%.
Each time you adjust the intensity, the direction of the adjustment (increase/
decrease) changes. Thus, if you first increase the intensity, the intensity will
be decreased the next time you adjust it.
You will hear short successive clicking sounds while the intensity is being
adjusted and a long signal tone when the maximum/minimum intensity is
reached.
21 Operating dental unit
Planmeca Compact i3 95
