User's manual
F1, F2 = Schurter 0001.1014 10A/250V/FAST ACTING/HIGH BR CAP.
(100V, 115V)
F1, F2 = Bussmann S501-10-R 10A 250V FAST ACTING/HIGH BR CAP.
(100V, 115V)
F1, F2 = Schurter 0001.1012 6.3A/250V/FAST ACTING/HIGH BR CAP.
(220V – 240V)
F1, F2 = Bussmann S501-6.3-R 6.3A 250V FAST ACTING/HIGH BR CAP.
(220V- 240V)
F3, F4 = 4A/250V/Fast act./High br. cap, Schurter 0001.1010 OR
Bussmann S501-4-R
F5 = 8A/250V/Fast act./High br. cap, Schurter 0001.1013 OR Bussmann
S501-8-R
F6 - F8 = 6.3A/250V/Fast act./High br. cap, Schurter 0001.1012 OR
Bussmann S501-6.3-R
Power consumption
Idle unit:
Typical average:
Maximum:
Electrical classification
Class I
Operation of chair lift and backrest motors
Intermittent operation, ED 6%, 25 sec "ON", 400 sec. "OFF"
Water supply
Pressure range:
Flow rate:
Quality:
pH:
Connection:
Backflow prevention:
Air supply
Pressure range:
Flow rate:
Humidity:
Quality:
Oil contamination:
Particulate
contamination:
≈ 60 VA (unit not in use, OP-light turned on)
≈ 350 VA (during patient treatment)
1450 VA (at maximum rated mains voltage, both
chair motors running)
min. 300kPa (44 psi), max. 900 kPa (130 psi)
≥ 4 l / min (maximum consumption at any
instance)
hardness; ≤ 8°dH
6.5 – 8.5
1/4"
The water supply line must be equipped with a
backflow prevention valve according to local
requirements. E.g. in most European countries
according to EN1717 standard, BA Type
backflow preventer.
min. 550 kPa (80 psi), max. 900 kPa (130 psi)
≥ 55 litres / minute (maximum consumption at
any instance)
dew point not greater than −20 °C at atmospheric
pressure
medical grade, dry and oil-free
3
max. 0.5 mg/m
≤ 100 particles per cubic meter for 1 μm to 5 μm
particle size
Planmeca Compact i3
32 Technical information
233
