About this Manual
1
1.2

Illustration of General Notices

Terms and Definitions
Terms that are specifically explained in the manual are highlighted as underlined and
green words.
All term definitions are to find in the glossary of the manual. In the PDF file a mouse
click on a highlighted term jumps directly to the according definition.
1.3

Abbreviations

HSPAM
n.c.
OSSD
SERVO
STO
SVC
VF
VCC
VECTOR
12
Risk symbol Description
Potentially risk of injury when working on machines with open covers/
doors
Risk of injury due to flying objects
Destruction risk of electrostatically sensitive components
Risk of property damage
Symbol Description
Hint with additional, further information
Tip with suggestions and useful information
high-speed pulse amplitude modulation
not connected
Output Signal Switching Device
servo control
safety function: Safe Torque Off
sensorless vector control
V/f Characteristic Curve
voltage at the common collector
vector control
Drive System SD2 - Hardware Description
