4.3 Channel Control Registers
The second section under the Channel Registers tab is the Channel Control Registers box. This panel
allows the user to uniquely configure the front-end multiplexer (mux) for each channel. Additionally, at the
top of the Channel Control Registers box is the option to globally set all channels to the same setting.
Table 9 lists the register map. The channel-specific mux is illustrated in
specific mux is shown in
Address Register
Channel-Specific Settings
05 CH1SET
06 CH2SET
07 CH3SET
08 CH4SET
09 CH5SET
0A CH6SET
0B CH7SET
0C CH8SET
Figure 14. Channel Control Register GUI Panel: Single Channel Enabled
Figure 15. Channel Control Registers GUI Panel: All Channels Enabled
16
Performance Demonstration Kit for the ADS131E08
Figure 15.
Table 9. Register Assignments: Channel-Specific Settings
Reset
Value Bit 7 Bit 6
00 PD1 GAIN12
0 PD2 GAIN22
0 PD3 GAIN32
0 PD4 GAIN42
0 PD5 GAIN52
0 PD6 GAIN62
0 PD7 GAIN72
0 PD8 GAIN82
Copyright © 2012–2020, Texas Instruments Incorporated
Figure
Bit 5 Bit 4 Bit 3
GAIN11 GAIN10 0
GAIN21 GAIN20 0
GAIN31 GAIN30 0
GAIN41 GAIN40 0
GAIN51 GAIN50 0
GAIN61 GAIN60 0
GAIN71 GAIN70 0
GAIN81 GAIN80 0
SBAU200C – June 2012 – Revised April 2020
www.ti.com
14, and the all-channel-
Bit 2 Bit 1 Bit 0
MUXn2 MUXn1 MUXn0
MUX22 MUX21 MUX20
MUX32 MUX31 MUX30
MUX42 MUX41 MUX40
MUX52 MUX51 MUX50
MUX62 MUX61 MUX60
MUX72 MUX71 MUX70
MUX82 MUX81 MUX80
