6.4 Remote Control Dip Switch

Open the Remote control back cover to adjust the dip-switch settings (ON/
OFF) to match the IR address setting in the OSD menu. Default setting is 0.
0
ON
1

6.5 RS-232 Protocols

OR-44VWC
PIN
1
2
3
4
5
6
7
8
9
Baud Rate: 115200bps
Data Bit: 8 bits
Parity: None
Flow Control: None
Stop Bit: 1
12
1
ON
2 1 2
Assignment
NC
TxD
RxD
NC
GND
NC
NC
NC
NC
2
ON
1 2
Remote Controller (PC)
PIN
1
2
3
►
4
◄
5
6
7
8
9
3
ON
1 2
Definition
NC
RxD
TxD
NC
GND
NC
NC
NC
NC
