CAUTION: Failure to follow the installation
instructions will cause inability to install lock.
Removal of Plastic Lock Plug and
Installation of Lock Cylinder
1.
Pull open plastic plug cover.
2.
While pressing the plug retainer tab to the right,
insert a coin or the head of a key into the slot and turn
o
90 clockwise. This will unlock the case. You will hear
the lock mechanism open.
CAUTION: Make sure you unlock the
case BEFORE proceeding to step 3.
3.
Push plug retainer tab down and remove plastic
plug from parent unit.
4.
Position lock cylinder tab at 45
Insert lock cylinder at a tilted angle so the tab will
collapse.
CAUTION: Make sure the tab is
o
located at 45 or 2:00 before
inserting lock cylinder.
5.
Push lock cylinder into the hole until it stops and
turn the lock plug assembly clockwise 45
(or the 3:00 position) and remove the key.
o
or (2:00 position.)
o
1
PLUG RETAINER TAB
2
TURN 90 o
C L
o
45
4
TAB
PLASTIC PLUG
COVER
3
COIN OR
HEAD OF KEY
PLUG RETAINER TAB
or 2:00
5
PLASTIC PLUG
o
45
or
3:00
