Technical specifications

Table 11: FEC26 technical specifications
Product Code Numbers
Supply Voltage
Power Consumption
Ambient Conditions
Addressing
Communications Bus
Processor
Memory
Input and Output Capabilities
Analog Input/Analog Output Resolution
and Accuracy
Terminations
Mounting
Housing
MS-FEC2611-0: 17-Point FEC
MS-FEC2611-0ET: FEC2611 Extended Temperature controller for rooftop applications.
Supports Operational Temperature Range of -40 °C to 70 °C (-40 °F to 158°F).
MS-FEC2621-0: 17-Point FEC with integral display and pushbutton user interface.
Smoke Control Models:
MS-FEC2611-0U
MS-FEC2621-0U
24 VAC (nominal, 20 VAC minimum/30 VAC maximum), 50/60 Hz, power supply Class 2
(North America), Safety Extra-Low Voltage (SELV) (Europe)
14 VA maximum for FEC2611 only
20 VA maximum for FEC2621 (with integral display) only
Note: VA rating does not include any power supplied to the peripheral devices
connected to Binary Outputs (BOs) or Configurable Outputs (COs), which can
consume up to 12 VA for each BO or CO; for a possible total consumption of an
additional 84 VA (maximum).
FEC26 Field Equipment Controller:
Operating: 0°C to 50°C (32°F to 122°F); 10% to 90% RH noncondensing
Storage: -40°C to 80°C (-40°F to 176°F); 5% to 95% RH noncondensing
FEC26 Extended Temperature Field Equipment Controller:
Operating: - 40 to 70°C (-40 to 158°F); 10 to 90% RH noncondensing
Storage: -40 to 80°C (-40 to 176°F); 5 to 95% RH noncondensing
BACnet
MS/TP: DIP switch set; valid field controller device addresses 4–127 (Device
®
addresses 0–3 and 128–255 are reserved and not valid controller addresses.)
N2: DIP switch set; valid controller device addresses 1–255
RS-485, field selectable between BACnet MS/TP and N2 communications:
3-wire FC Bus between supervisory controller and field controllers.
4-wire SA Bus between field controller, network sensors, and other sensor/actuator
devices, includes a lead to source 15 VDC supply power (from field controller) to bus
devices.
N2 Open Protocol:
N2/FC Bus: 1.0mm (18 AWG) standard 3-wire, twisted, shielded cable recommended
between the supervisory controller and field controllers
FEC26 Series: H8SX/166xR Renesas
640 KB flash memory and 128 KB RAM
FEC26 Series:
6 - Universal Inputs: Defined as 0–10 VDC, 4-20 mA, 0–600k ohm, or Binary Dry Contact
2 - Binary Inputs: Defined as Dry Contact Maintained or Pulse Counter/Accumulator
Mode
3 - Binary Outputs: Defined as 24 VAC Triac (selectable internal or external source power)
4 - Configurable Outputs: Defined as 0–10 VDC or 24 VAC Triac BO
2 - Analog Outputs: Defined as 0–10 VDC or 4–20 mA
Input: 16-bit resolution
Output: 16-bit resolution, +/- 200 mV accuracy in 0-10 VDC applications
Input/Output: Fixed Screw Terminal Blocks
SA/FC Bus and Supply Power: 4-Wire and 3-Wire Pluggable Screw Terminal Blocks
SA/FC Bus Port: RJ-12 6-Pin Modular Jacks
Horizontal on single 35 mm DIN rail mount (preferred), or screw mount on flat surface
with three integral mounting clips on controller
Enclosure material: ABS and polycarbonate, Rating V0 minimum
Protection Class: IP20 (IEC529)
32-bit microcontroller
®
FEC26 Field Equipment Controllers Installation Guide
23
