Arbor Technology ITX-i2701 Quick Installation Manual

Mini-itx industrial motherboard

Advertisement

Quick Links

ITX-i2701/ITX-i2701D
Form Factor
Mini-ITX
VGA
Dual Channels LVDS/
Analog RGB/ TV-out /
SDVO
I/O
PCI/ Mini Card/ SATA/
USB/ COM/ LPT
♦ Technical Support
If you have any technical difficulties, please consult the user's manual first at:
ftp://ftp.arbor.com.tw/pub/manual
Please do not hesitate to call or e-mail our customer service when you still can not
find out the answer.
http://www.arbor.com.tw
E-mail: info@arbor.com.tw
P/N: 4041270101130P
Mini-ITX Industrial Motherboard
CPU
Soldered onboard Intel®
Atom N270 1.6GHz
Processor
LAN
2 x Realtek 8111 PCIe
Gigabit Ethernet
- 1 -
Quick Installation Guide
Chipset
Intel® 945GSE
Intel® ICH7M
Audio
Realtek ALC888 HD Audio
Codec, Line-in/ Line-out/
Mic-in
Copyright
2011 All Rights Reserved.
®
Version 1.3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ITX-i2701 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Arbor Technology ITX-i2701

  • Page 1 ITX-i2701/ITX-i2701D Mini-ITX Industrial Motherboard Quick Installation Guide Version 1.3 Form Factor Chipset Mini-ITX Soldered onboard Intel® Intel® 945GSE Atom N270 1.6GHz Intel® ICH7M Processor Audio Dual Channels LVDS/ 2 x Realtek 8111 PCIe Realtek ALC888 HD Audio Analog RGB/ TV-out /...
  • Page 2: Packing List

    Mini-ITX Intel Atom™ N270 1.6GHz slim type industrial motherboard ITX-i2701 with Analog RGB/ LCD, 6 COMs, Audio and GbE LAN ITX-i2701D ITX-i2701 with onboard soldered 4GB NANDrive Cable Kit 1 x IDE Cable 1 x USB Cable 1 x LPT Cable 1 x TV-out Cable 1 x Keyboard &...
  • Page 3: Specifications

    Specifications Form Factor Mini-ITX industrial motherboard Intel® Atom™ N270 CPU 1.6GHz w/ 533MHz FSB Chipset Intel® 945GSE + ICH7M System Memory Soldered onboard 1GB DDR2 533MHz SDRAM VGA/ LCD Controller Intel® Graphics Media Accelerator 950 integrated Ethernet 2 x Realtek 8111 PCIe Gigabit Ethernet LAN I/O Chips Winbond W83627HG BIOS...
  • Page 4: Board Dimensions

    Board Dimensions 107.59 13.00 92.60 16.10 29.60 16.97 6.33 157.48 127.48 17.39 92.34 17.70 67.52 41.98 17.25 Unit: mm 16.80 - 4 -...
  • Page 5 Jumpers/ Connectors Quick Reference Connectors Label Function Label Function 12VIN1 DC 12V Power Input LPT1 Parallel Port Connector 4W_T1 4 Wire Touch FPC Connector LVDS1 LVDS Connector 4W_T2 4 Wire Touch Connector PCI Express Mini-Card socket 5W_T1 5 Wire Touch Connector PCI1 32-bit PCI Interface Slot AC-Link Connector...
  • Page 6: Jumpers & Connectors Location

    Jumpers & Connectors Location 4W_T1 LVDS1 SAPO1 SDVO1 SAPO2 JVLCD1 4W_T2 SATA1 COM5 12VIN1 T_LED1 LPT1 JPWR1 KBMS1 EATX1 SMBUS1 5W_T1 JTS1 IDE1 DIO1 USB3 AUDIO1 JFRT1 JBAT1 INV1 SPDIF1 FAN1 JNAND1 ( For TX-i2701D only) PCI1 JRS3 COM1 JRS4 VGA1 COM2 COM3...
  • Page 7: Jumper Settings

    Jumpers Jumper Settings J2, J3: COM3 Port RS-232/ 422/ 485 Output Selection The jumper is “short” (closed) when the jumper cap is placed on pins. If not, that means the jumper is “open”. Connector type: 2.00mm pitch 2x3-pin headers. Description Pin 1-2 short Pin short Pin 2-3 short...
  • Page 8: Jbat1: Clear Cmos Setting

    Connectors JV1: COM1 Port Power Selection T_LED1: Touch Screen LED indicator Select voltage level for Pin-10 of COM1 port. Connector type: 2.00mm pitch 1x3-pin headers. Connector type: 2.54mm pitch 1x2-pin headers. Mode Description Sets Pin-10 signal to +5V Positive (Default) Sets Pin-10 signal to +12V JV5: COM5/ COM6 Port Power Selection EATX1: ATX Feature Connector...
  • Page 9 LVDS1: LVDS Connector JFRT1: Switches and Indicators Connector type: DF-13-30DP-1.25V connector Once connected with case-mounted buttons, these connectors will act as LED indicators and switches for Pin Desc. Pin Desc. the computer status and activity. Connector type: 2.00mm pitch 1x8-pin box wafer connector TX2CLK+ TX1CLK+ Description...
  • Page 10 INV1: LCD Inverter Connector TV1: TV-out Connector Connector type: 2.00mm pitch 1x5 box wafer Connector type: 2.00mm pitch 1x6-pin box wafer connector. connector Description Composite Video +12V CVBS Unused Backlight on/off Unused Brightness control S-Video Unused Luminance AC1: HD AUDIO daughter board connector Chrominance Connector type: 2.00mm pitch 1x9 box wafer connector.
  • Page 11 SATA1: Serial ATA Connectors KBMS1: Keyboard & Mouse Connector High speed transfer rates (150MB/s). Connector type: 2.0mm pitch 1x6-pin box wafer connector. Description KB_DATA COM5: Serial Ports Connector This connector includes two RS-232 serial ports. MS_DATA Connector type: 2.00mm pitch 2x10-pin box headers. KB_CLK PS2_VCC Port...
  • Page 12: Mini-Card Socket

    MC1: Mini-Card Socket VGA1: Analog RGB Connector Connector type: VGA: D-Sub 15-pin female Mini-Card Pin Desc. Pin Desc. Desc. Socket GREEN VDDAT BLUE HSYNC COM1: RS-232 Connector VSYNC Connector type: 2.00mm pitch 2x5-pin box headers. VDCLK Pin Desc. Desc. USB1~2: Double Stacks USB type A DCD# Connectors DTR#...

This manual is also suitable for:

Itx-i2701d
