  • Page 1 ITX-i87H0 Mini-ITX Industrial Motherboard User’s Manual Version 1.0 2015.04...
  • Page 2 This page is intentionally left blank. - II -...

  • Page 3: Revision History

    Revision History Version Release Time Description April, 2015 Initial release - i -...
  • Page 4 This page is intentionally left blank. - ii -...

  • Page 5: Table Of Contents

    Contents Table of Contents Revision History .................i Table of Contents ................iii Preface....................v Copyright Notice ..................v Declaration of Conformity ............... v CE ....................v FCC Class A ................... vi RoHS ....................vi SVHC / REACH ................vii Warning ....................vii Replacing Lithium Battery ..............vii Technical Support ..................vii Warranty....................viii Chapter 1 - Introduction ..............1...
  • Page 6 Contents 3.2.9. Intel(R) Rapid Start Technology ........... 52 3.2.10. Intel(R) Smart Connect Technology ........53 3.2.11. Super IO Configuration ............54 3.2.12. Intel ME BIOS Extension Configuration ......55 3.3. Chipset ................... 56 3.3.1. System Agent Configuration ..........57 3.3.2. PCH Information ..............58 3.3.3.

  • Page 7: Preface

    Preface Preface Copyright Notice All Rights Reserved. The information in this document is subject to change without prior notice in order to improve the reliability, design and function. It does not represent a commitment on the part of the manufacturer. Under no circumstances will the manufacturer be liable for any direct, indirect, special, incidental, or consequential damages arising from the use or inability to use the product or documentation, even if advised of the possibility of such...

  • Page 8: Fcc Class A

    (PBDE) in electrical and electronic products. Member states of the EU are to enforce by 7/1/2006. ARBOR Technology Corp. hereby states that the listed products do not contain unintentional additions of lead, mercury, hex chrome, PBB or PBDB that exceed a maximum concentration value of 0.1% by weight or for cadmium exceed...

  • Page 9: Svhc / Reach

    Preface SVHC / REACH To minimize the environmental impact and take more responsibility to the earth we live, Arbor hereby confirms all products comply with the restriction of SVHC (Substances of Very High Concern) in (EC) 1907/2006 (REACH --Registration, Evaluation, Authorization, and Restriction of Chemicals) regulated by the European Union.

  • Page 10: Warranty

    Preface Warranty This product is warranted to be in good working order for a period of two years from the date of purchase. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms.

  • Page 11: Chapter 1 Introduction

    Chapter 1 Introduction Chapter 1 - Introduction - 1 -...

  • Page 12: Product Highlights

    Introduction 1.1. Product Highlights • Generation Intel Core™ Processor supported ® • Gigabit Ethernet Port • Dual Channel 24-bit LVDS, DisplayPort, HDMI_IN and HDMI_OUT • Dual Independent Displays supported 1.2. About this Manual This manual is intended for experienced users and integrators with hardware knowledge of computers.

  • Page 13: Specifications

    Introduction 1.3. Specifications Form Factor Mini-ITX industrial motherboard Intel® 4 Generation Core Family processors in LGA1150 socket Chipset Intel® PCH H87 2 x 204-pin DDR3 SO-DIMM socket supporting 1600/1333 System Memory MHz SDRAM up to 16GB ® Graphic Chipset Integrated Intel HD Graphics 1 x HDMI_OUT port 1 x HDMI_IN port...

  • Page 14: Inside The Package

    ® 1.4. Inside the Package Before starting to install the single board, make sure the following items are shipped: 1 x ITX-i87H0 Industrial Motherboard 1 x Driver CD 1 x Quick Installation Guide 1 x I/O bracket 1 x DC 2.5 Jack to 7.4 Plug Cable If any of the aforelisted items is damaged or missing, contact your vendor immediately.

  • Page 15: Ordering Information

    Introduction 1.5. Ordering Information Socket LGA1150 for 4 Generation Intel Core™ Processor ® ITX-i87H0 i7/ i5/ i3, Pentium / Celeron / H87 Mini-ITX motherboard ® ® Optional Accessories CPF-67Q0-C1 CPU cooler for Intel LGA1155/1156 processor Cable kit 2 x Two Ports USB2.0 cables 1 x One Port USB2.0 cable...

  • Page 16: Ram Installation

    Introduction 1.6. RAM Installation The main board has one memory module (SO-DIMM) sockets. Load the computer with a memory module of higher capacity to make programs run faster. The memory module for the computer’s SO-DIMM socket should be a DDR3L with a “key notch”...

  • Page 17: Cpu Installation

    1.7. CPU Installation The LGA1150 processor socket comes with a lever to secure the processor. Please refer to the pictures step by step as below and note that the cover of the LGA1150 socket must always be installed during transportation to avoid damage to the socket.
  • Page 18 This page is intentionally left blank. - 8 -...

  • Page 19: Chapter 2 Getting Started

    Chapter 2 Getting Started Chapter 2 - Getting Started - 9 -...

  • Page 20: Board Dimensions

    Getting Started 2.1. Board Dimensions - 10 -...

  • Page 21: Block Diagram

    Getting Started 2.2. Block Diagram Socket LGA1150 SO-DIMM1, 2 DDIB for 4 Gen. Dual Channel DDR3 DisplayPort Conn. 2 x 204-pin DDR3 1600MT/s Intel Core™ ® SO-DIMM socket i7/i5/i3 Pentium HDMI_OUT ® DDIC 1 x eDP Dual Channel LVDS RTD2486HXD HDMI Type A Conn.

  • Page 22: Jumpers & Connectors

    The board comes with some connectors to join some devices and also some jumpers to alter the hardware configuration. The following in this chapter will explicate each of these components one-by-one. 2.3.1. Layout This section will provide an overview of this board. ITX-i87H0 - 12 -...

  • Page 23: Jumpers

    Getting Started 2.3.2. Jumpers LCD_SEL Function: LCD Resolution Selection Setting: Jumper Type: 2.54mm pitch 2x4-pin headers Description BOE 23.6” None HM236WU1-400 BOE 21.5” B3HT15F01-100 CMO 23.6 M236HGE-L20 CPT 21.5” CLAA215FA04 Board Top LCD_SEL ITX-i87H0 - 13 -...
  • Page 24 Getting Started CLR_CMOS Function: Clears/keeps CMOS Setting: Jumper Type: 2.54mm pitch 1x3-pin header Pin Description Keep CMOS (Default) Clear CMOS Board Top ITX-i87H0 CLR_CMOS - 14 -...
  • Page 25 Getting Started ME_UNLOCK Function: ME unlock header Setting: Jumper Type: 2.54mm pitch 1x2-pin header Description Short Unlock Open Lock Board Top ITX-i87H0 ME_UNLOCK - 15 -...

  • Page 26: Connectors

    Getting Started 2.3.3. Connectors SATA1&2 Function: Serial ATA Connectors Pin Assignment: Connector Type: Lockable SATA connectors with housing The pin assignments conform to the industry standard. Board Top ITX-i87H0 SATA1 SATA2 - 16 -...
  • Page 27 Getting Started SYS_FAN&CPU_FAN Function: Fan power connector Pin Assignment: Connector Type: Onboard 1 x 4-pin one-wall Pin Description wafer connector +12V FAN_Detect CTRL Note: The fan must be a 12V fan. Board Top ITX-i87H0 CPU_FAN SYS_FAN - 17 -...
  • Page 28 Getting Started Function: Consumer Infrared Header Pin Assignment: Connector Type: 2.54mm pitch 2x4-pin headers Pin Desc. Pin Desc. PWR +5V 6 PWR +5V CIR RX Board Top ITX-i87H0 - 18 -...
  • Page 29 Pin Assignment: headers Type: Pin Desc. Pin Desc. HD LED(+) MSG LED (+) HD LED(-) MSG LED (-) Reset Switch (-) 6 Power Switch (+) Reset Switch (+)8 Power Switch (-) Reserved 10 N/C Board Top ITX-i87H0 F_PANEL - 19 -...
  • Page 30 Getting Started DC_IN Function: DC jack Pin Assignment: Connector Type: DC Φ7.4 Male connector Inner Shell :19V DC Outer Shell :GND Board Top ITX-i87H0 DC_IN - 20 -...
  • Page 31 Getting Started LVDS Function: LVDS Connector (40-Pin) Connector Type: 0.5mm pitch 40-pin coaxial connector Pin Assignment: Assignment Assignment ODD Lane3 + ODD Lane3 - Power +3.3V ODD Lane2 + ODD Lane2 - ODD Lane1 + ODD Lane1 - ODD_Clock + ODD Lane0 + ODD_Clock - ODD Lane0 -...
  • Page 32 Getting Started MON_SW Function: LVDS brightness switch header Pin Assignment: Connector Type: 2.54mm pitch 1x2-pin headers Desc. LCD Backlight Board Top LVDS MON_SW ITX-i87H0 - 22 -...
  • Page 33 Getting Started DISP_BRT Function: Display brightness header Pin Assignment: Connector Type: 2.00mm pitch 1x8-pin box Pin Desc. headers LCD BKL ON/OFF LCD BKL adjustment LCD BKL Power +19V LCD BKL Power +19V LCD BKL Increase LCD BKL decrease Function: Buzzer header(Optional) Pin Assignment: Connector Type: 2.54mm pitch 1x4-pin headers Desc.
  • Page 34 Getting Started Board Top USB_CR_CAM DISP_BRT ITX-i87H0 - 24 -...
  • Page 35 Getting Started F_USB Function: 10-pin USB 2.0 header supports card reader and camera or other USB 2.0 devices Connector 2.54mm pitch 2x5-pin Pin Assignment: headers Type: Pin Desc. Pin Desc. USB Port A (-) 4 USB Port B (-) USB Port A (+)6 USB Port B (+) 10 N/C DMIC...
  • Page 36 Getting Started Board Top F_USB ITX-i87H0 DMIC SPKR - 26 -...
  • Page 37 Getting Started F_AUDIO Function: Front Panel Audio Header Pin Assignment: Connector 2.54mm pitch 2x5-pin Pin Desc. Pin Desc. headers Type: FP_MIC_in Analog_GND MIC_Power 4 Presence# FP_Right Sense1_Return Sense_Send 8 FP_Left Sense2_Return MIC&LINE_OUT Function: Microphone&Line-out Pin Assignment: Connector Type: ø3.5mm stereo audio The pin assignments jacks conform to the...
  • Page 38 Getting Started Board Top ITX-i87H0 F_AUDIO LINEOUT - 28 -...
  • Page 39 50 N/C 10 UIM_DATA_A 25 PE_CAD3_RX+ 40 GND 51 N/C 11 REFCLK- 26 GND 41 +3.3V 52 +3.3V 12 N/C 27 GND 13 REFCLK+ 28 +1.5V 14 N/C 29 GND 15 GND 30 SMB_CLK Board Top ITX-i87H0 - 29 -...
  • Page 40 50 N/C 10 UIM_DATA_A 25 PE_CAD3_RX+ 40 GND 51 N/C 11 REFCLK- 26 GND 41 +3.3V 52 +3.3V 12 N/C 27 GND 13 REFCLK+ 28 +1.5V 14 N/C 29 GND 15 GND 30 SMB_CLK Board Top ITX-i87H0 - 30 -...
  • Page 41 Getting Started CASE Function: Chassis Intrusion detect header Pin Assignment: Connector Type: 2.54mm pitch 1x2-pin headers Desc. Chassis cover is Short removed Chassis cover is Open closed USB3R1,2 Function: USB 3.0 Connector Pin Assignment: Connector Type: USB 3.0 Type A connector The pin assignments conform to the industry standard.
  • Page 42 Getting Started Board Top ITX-i87H0 CASE USB3R2 USB3R1 HDMI_OUT - 32 -...
  • Page 43 Connector Type: HDMI-IN connector The pin assignments conform to the industry standard. SATA_PWR Function: Serial ATA Power Connector Pin Assignment: Connector Type: SATA power connector The pin assignments conform to the industry standard. Board Top ITX-i87H0 SATA_PWR HDMI_IN - 33 -...

  • Page 44: Pin Assignment

    USB 3 ICC Port1 SuperSpeed Tx− SuperSpeed Tx+ USB 3 ICC Port2 SuperSpeed Tx+ USB 3 ICC Port1 D− USB 3 ICC Port2 USB 3 ICC Port1 D+ D− USB 3 ICC Port2 Board Top ITX-i87H0 USB3F - 34 -...
  • Page 45 Getting Started DIMM1 Function: SO-DIMM connectors Connector Type: SO-DIMM connectors Pin Assignment: The pin assignments conform to the industry standard. Board Top ITX-i87H0 SODIMM1/2 - 35 -...
  • Page 46 Getting Started USB _TP Function: 5-pin USB 2.0 header Pin Assignment: Connector Type: 2.54mm pitch 1x5-pin headers Desc. USB- USB+ Board Top ITX-i87H0 USB_TP - 36 -...

  • Page 47: Driver Installation Notes

    \ITX-i87H0\ME\Win 8\32bits_ME9.0_5M_V9.0.2.1345 \ITX-i87H0\ME\Win 8\64bits\MEI_Win8.1_5.0M_9.5.15.1730_PV \ITX-i87H0\CIR\Win 8 Windows 7 Driver Path \ITX-i87H0\Chipset\Win 7\32bit CHIPSET \ITX-i87H0\Chipset\Win 7\64bit \ITX-i87H0\Graphic\Win 7\win32_1536b GRAPHIC \ITX-i87H0\Graphic\Win 7\Win64_153117 ETHERNET \ITX-i87H0\Ethernet\Win 7 \ITX-i87H0\AUDIO\Win 7\32bit AUDIO \ITX-i87H0\AUDIO\Win 7\64bit \ITX-i87H0\ME\Win 7\32bits_ME9.0_5M_V9.0.2.1345 \ITX-i87H0\ME\Win 7\WIN7 64bits \ITX-i87H0\CIR\Win 7 \ITX-i87H0\USB3.0\32bits_USB3_V2.5.0.19 USB3.0 \ITX-i87H0\USB3.0\64bits_USB_3.0_Win7_2.5.1.28 - 37 -...
  • Page 48 This page is intentionally left blank. - 38 -...

  • Page 49: Chapter 3 - Bios

    Chapter 3 BIOS Chapter 3 - BIOS - 39 -...
  • Page 50 BIOS The BIOS Setup utility is featured by AMI BIOS to configure the system settings stored in the system’s BIOS ROM. AMI BIOS is activated once the computer powers on. After entering the utility, use the left/right arrow keys to navigate between the top menus and use the down arrow key to access one.

  • Page 51: Main

    BIOS 3.1. Main The Main menu features the settings of System Language, System Date and System Time. The featured settings are: Setting Description System Language Sets system Language. System Time Sets system time. System Date Sets system date. - 41 -...

  • Page 52: Advanced

    BIOS 3.2. Advanced The Advanced menu controls the system’s CPU, ACPI, Super IO, SATA and USB, etc... It also helps users monitor hardware health. The featured submenus are: Submenu Description LAN Configuration 3.2.1. LAN Configuration on page 43. PC Health Status 3.2.3.

  • Page 53: Lan Configuration

    BIOS 3.2.1. LAN Configuration Access this submenu to configure the LAN-related information that the BIOS automatically detects. The featured submenus are: Setting Description Onboard LAN Enables/disables Onboard LAN 1 controller. Controller Enabled is the default. - 43 -...

  • Page 54: Power Management Setup

    BIOS 3.2.2. Power Management Setup Access this submenu to setup some parameters for system power management operation. The featured submenus are: Setting Description Enables/disables Resume By RING. An input signal on the serial Ring Indicator (RI) line (in other words, an Resume By RING incoming call on the modem) awakens the system from a soft off state.

  • Page 55: Pc Health Status

    BIOS Enables/disables Resume By RTC Alarm. The system can be turned off with a software command. If you enable this item, the system can automatically resume at a fixed time based on Resume By RTC the system’s RTC (realtimeclock). Use the items below this one to set Alarm the date and time of the wake-up alarm.

  • Page 56: Acpi Settings

    BIOS 3.2.4. ACPI Settings Access this submenu to configure the highest ACPI sleep state when the system enters suspend. The featured submenus are: Setting Description Sets the highest ACPI sleep state that system enters when the suspend button is hit. ACPI Sleep State Options available are: Suspend Disabled...

  • Page 57: Cpu Configuration

    BIOS 3.2.5. CPU Configuration Access this submenu to setup the CPU Configuration. The featured submenus are: Setting Description Genuine Intel(R) CPU Display the CPU info installed in your computer. 0000 @ 2.80GHz Enables/disables the Hyper-threading. Hyper-threading Enabled is the default. Active Processor Sets the number of Active Processor Cores.
  • Page 58 BIOS Enables/disables the maximum CPUID value limit. Limit CPUID Enable this item to prevent the system from “rebooting” when trying to Maximum install Windows XP. Disabled is the default. Enables/disables the Excute Disable Bit. It allows the processor to classify areas in memory by where application code can execute and where it cannot.

  • Page 59: Sata Configuration

    BIOS 3.2.6. SATA Configuration Access this submenu to view SATA device(s) information and also to configure SATA device(s). The featured settings are: Setting Description Sets the SATA mode. SATA Mode Selection Options available are Disabled, IDE Mode ,and AHCI Mode(default). This motherboard supports two SATA channels and one mSATA channel, each channel allows one SATA/mSATA device to be installed.

  • Page 60: Usb Configuration

    BIOS 3.2.7. USB Configuration Access this submenu to view SATA device(s) information and also to configure SATA device(s). The featured settings are: Setting Description Enables/disables all USB devices. All USB Devices Enabled is the default. Legacy USB Enables/disables legacy USB support. Support Enabled is the default.

  • Page 61: Trusted Computing

    BIOS 3.2.8. Trusted Computing Access this submenu to view SATA device(s) information and also to configure SATA device(s). The featured settings are: Setting Description Enables/disables the TPM port. TPM Support Enabled is the default. Enables/disables the security device. TPM State Disabled is the default.

  • Page 62: Intel(R) Rapid Start Technology

    BIOS 3.2.9. Intel(R) Rapid Start Technology Access this submenu to view SATA device(s) information and also to configure SATA device(s). The featured settings are: Setting Description Intel(R) Rapid Start Enables/disables the Intel(R) Rapid Start Technology. Technology Disabled is the default. - 52 -...

  • Page 63: Intel(R) Smart Connect Technology

    BIOS 3.2.10. Intel(R) Smart Connect Technology Access this submenu to view SATA device(s) information and also to configure SATA device(s). The featured settings are: Setting Description Enables/disables the ISCT configuration. ISCT Configuration Disabled is the default. - 53 -...

  • Page 64: Super Io Configuration

    BIOS 3.2.11. Super IO Configuration Access this submenu to view SATA device(s) information and also to configure SATA device(s). The featured settings are: Setting Description F71808A Super IO Chip Display the information of the super IO chip CIR Controller Enables/disables the CIR Controller Configuration. Configuration Enabled is the default.

  • Page 65: Intel Me Bios Extension Configuration

    BIOS 3.2.12. Intel ME BIOS Extension Configuration Access this submenu to view SATA device(s) information and also to configure SATA device(s). The featured settings are: Setting Description Enables/disables the Intel Active Management Technology (Intel AMT). Intel AMT Disabled is the default. BIOS Hotkey Enables/disables the BIOS hotkey pressed.

  • Page 66: Chipset

    BIOS 3.3. Chipset Access this Chipset menu to configure the system’s chipset. The featured submenu are covered in the following sections: Submenu Description System Agent Configures the System Agent. Configuration 3.3.1. System Agent Configuration on page for more details. Configures the PCH PCH Configuration 3.3.2.

  • Page 67: System Agent Configuration

    BIOS 3.3.1. System Agent Configuration Access this submenu to configure SoC parameters. The featured settings are: Setting/Submenu Description Sets the Initial Graphic Adapter Initial Graphic Adapter Options are: Auto(default), PCI Express, PCI Sets the DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size IGD Memory used by the Internal Graphics Device.

  • Page 68: Pch Information

    BIOS 3.3.2. PCH Information Access this submenu to configure the system agent. The featured settings are: Setting Description Restore AC Power Sets the status of PC after the power loss. Loss Options are: Power Off (default), 256M Power On, Last state. Azalia HD Audio Enables/disables Azalia HD Audio.

  • Page 69: Me Information

    BIOS 3.3.3. ME Information Access this submenu to configure the system agent. The featured settings are: Setting Description ME Control Enables/disables ME Firmware. Enabled is the default. ME FW Version Display the ME Firmware Version - 59 -...

  • Page 70: Tweak

    BIOS 3.4. Tweak The Feature menu sets up the clock speed and system bus for your system. The featured settings are: Setting Description CPU OverClocking Configures the CPU Overclocking. Configuration 3.4.1. CPU OverClocking Configuration on page 61. North Bridge Configures the CPU Overclocking. Configuration 3.4.2.

  • Page 71: Cpu Overclocking Configuration

    BIOS 3.4.1. CPU OverClocking Configuration Access this submenu to configure CPU OverClocking parameters. The featured settings are: Setting/Submenu Description CPU Ratio This item allows users to control non turbo CPU ratio. Enables/disables Package Current Lock Package Current Lock Disabled is the default. Sets IA Core Current IA Core Current Maximum is the default.
  • Page 72 BIOS Sets the Long Duration Power Limit Override Long Duration Power Limit Intel(R) Turbo Boost Technology will use this power limit during the Override long duration power limit time window. Maximum is the default. Sets the power limit 1 time Power Limit 1 Time 8 is the default.

  • Page 73: North Bridge Configuration

    BIOS 3.4.2. North Bridge Configuration Access this submenu to configure North Bridge parameters. The featured settings are: Setting/Submenu Description Sets the internal GFX core ratio Graphics Core Ratio Limit 20 is the default. - 63 -...

  • Page 74: Boot

    BIOS 3.5. Boot Access this menu to change system boot settings. The featured submenu is: Setting Description Sets Operation system type. Options are: Operation System Windows 7 or other OS: Boot Policy for Legacy OS Select Windows 8.x: Boot policy for UEFI OS Without Compatibility Support Module (CSM) Manual: User customized CSM parameters &...
  • Page 75 BIOS Sets whether to enable or disable the keyboard’s NumLock state Bootup NumLock State when the system starts up. Options available are On (default) and Off. Sets the Boot Mode Boot mode select Options available are Legacy (default) and UEFI. Set Boot Priority Sets boot priority for all boot devices.

  • Page 76: Security

    BIOS 3.6. Security The Security menu sets up the administrator password. Once an administrator password is set up, this BIOS Setup utility is limited to access and will ask for the password each time any access is attempted. The featured settings are: Setting Description To set up an administrator password:...
  • Page 77 BIOS 3.7. Exit The Exit menu features a handful of commands to launch actions from the BIOS Setup utility regarding saving changes, quitting the utility and recovering defaults. The featured settings are: Setting Description Saves the changes and quits the BIOS Setup utility. Save Changes This is a command to launch an action from the BIOS Setup utility.
  • Page 78 BIOS Save Changes Save the changes that you have made. Discard Changes Discard any changes that you have made. Loads the defaults to all settings. This is a command to launch an action from the BIOS Setup utility. Restore Defaults When prompted for confirmation, select OK to load the defaults, or select Cancel to return to the BIOS setup.

  • Page 79: Appendices

    Appendices Appendices - 69 -...

  • Page 80: Appendix A. I/O Port Address Map

    Appendices Appendix A. I/O Port Address Map Each peripheral device in the system is assigned a set of I/O port addresses which also becomes the identity of the device. The following table lists the I/O port addresses used. Address Device Description 0x00000000-0x0000001F Direct memory access controller 0x00000081-0x00000091...
  • Page 81 Appendices Address Device Description 0x00000061-0x00000061 Motherboard resources 0x00000063-0x00000063 Motherboard resources 0x00000067-0x00000067 Motherboard resources 0x00000092-0x00000092 Motherboard resources 0x000000B2-0x000000B3 Motherboard resources 0x00000680-0x0000069F Motherboard resources 0x0000FFFF-0x0000FFFF Motherboard resources 0x0000FFFF-0x0000FFFF Motherboard resources 0x0000FFFF-0x0000FFFF Motherboard resources 0x00001C00-0x00001CFE Motherboard resources 0x00001D00-0x00001DFE Motherboard resources 0x00001E00-0x00001EFE Motherboard resources 0x00001F00-0x00001FFE Motherboard resources 0x00001800-0x000018FE...
  • Page 82 Appendices Address Device Description 0x000000B8-0x000000B9 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller 0x000004D0-0x000004D1 Programmable interrupt controller 0x0000F040-0x0000F05F SM Bus Controller 0x0000F0B0-0x0000F0B7 Standard AHCI 1.0 Serial ATA Controller 0x0000F0A0-0x0000F0A3 Standard AHCI 1.0 Serial ATA Controller 0x0000F090-0x0000F097 Standard AHCI 1.0 Serial ATA Controller 0x0000F080-0x0000F083 Standard AHCI 1.0 Serial ATA Controller 0x0000F060-0x0000F07F...

  • Page 83: Appendix B. Interrupt Request Lines (Irq)

    Appendices Appendix B. Interrupt Request Lines (IRQ) Peripheral devices use interrupt request lines to notify CPU for the service required. The following table shows the IRQ used by the devices on board. Level Function IRQ0 System timer IRQ4 Ethernet Controller IRQ8 System CMOS/real time clock IRQ10...

  • Page 84: Appendix C. Bios Memory Map

    Appendices Appendix C. BIOS Memory Map Address Device Description Resource Device 0xF7C00000-0xF7CFFFFF Ethernet Controller 0xF0000000-0xF00FFFFF Ethernet Controller 0xF7D14000-0xF7D17FFF High Definition Audio Controller 0xF7D10000-0xF7D13FFF High Definition Audio Controller 0xFED00000-0xFED003FF High precision event timer 0xFF000000-0xFFFFFFFF Intel(R) 82802 Firmware Hub Device 0xFF000000-0xFFFFFFFF Motherboard resources 0xFED1C000-0xFED1FFFF Motherboard resources 0xFED10000-0xFED17FFF...
  • Page 85 Appendices Address Device Description 0xF7D1B000-0xF7D1B3FF Standard Enhanced PCI to USB Host Controller 0xF7D1C000-0xF7D1C3FF Standard Enhanced PCI to USB Host Controller 0xF7800000-0xF7BFFFFF Standard VGA Graphics Adapter 0xE0000000-0xEFFFFFFF Standard VGA Graphics Adapter 0xA0000-0xBFFFF Standard VGA Graphics Adapter 0xFED40000-0xFED44FFF Trusted Platform Module 1.2 0xF7D00000-0xF7D0FFFF Universal Serial Bus (USB) Controller - 75 -...
