ITX-i2705/ITX-i2705D
Form Factor
Mini-ITX
VGA
Dual Channels LVDS/
Analog RGB/ TV-out
I/O
PCI/ Mini-Card/ SATA/
USB/ COM/ LPT
♦ Technical Support
If you have any technical difficulties, please consult the user's manual first at:
ftp://ftp.arbor.com.tw/pub/manual
Please do not hesitate to call or e-mail our customer service when you still can not
find out the answer.
http://www.arbor.com.tw
E-mail: info@arbor.com.tw
P/N: 4041270502130P
Mini-ITX Industrial Motherboard
CPU
Soldered onboard Intel®
Atom™ N270 1.6GHz
Processor
LAN
1 x Realtek 8111 PCIe
10/100/1000 Base-T
Ethernet
Copyright
- 1 -
Quick Installation Guide
Chipset
Intel® 945GSE
Intel® ICH7M
Audio
Realtek ALC888 HD Audio
Codec, Line-in/ Line-out/
Mic-in
2011 All Rights Reserved.
®
Version 1.3
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Arbor Technology ITX-i2705D
Summary of Contents for Arbor Technology ITX-i2705D
-
Page 1: Technical Support
ITX-i2705/ITX-i2705D Mini-ITX Industrial Motherboard Quick Installation Guide Version 1.3 Form Factor Chipset Mini-ITX Soldered onboard Intel® Intel® 945GSE Atom™ N270 1.6GHz Intel® ICH7M Processor Audio Dual Channels LVDS/ 1 x Realtek 8111 PCIe Realtek ALC888 HD Audio Analog RGB/ TV-out... -
Page 2: Packing List
Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x ITX-i2705/ITX-i2705D Mini-ITX industrial Motherboard 1 x Driver CD 1 x Quick Installation Guide Ordering Information Mini-ITX Intel® Atom™ N270 1.6GHz slim type industrial motherboard with... -
Page 3: Specifications
Support SPDIF output 1 x Parallel ATA (Ultra ATA/33) interface Storage 2 x Serial ATA with 150MB/s HDD transfer rate Soldered onboard 4GB NANDrive (ITX-i2705D only) 6 x COM ports (COM1, 2, 5, 6: RS-232, Serial Port COM3, 4: RS-232/422/485 selectable) -
Page 4: Board Dimensions
Board Dimensions 107.59 92.60 29.60 16.10 16.97 9.00 6.33 157.48 17.39 127.48 92.34 17.7 67.52 41.98 17.25 Unit: mm 16.8 - 4 -... - Page 5 Jumpers/Connectors Quick Reference Connectors Label Function Label Function 12VIN1 DC 12V Power Input LAN1 Ethernet RJ-45 Connector DCIN2 DC 12V Power Jack LPT1 Parallel Port Connector 4W_T1, LVDS1 LVDS Connector 4-Wire Touch FPC Connector 4W_T3 PCI Express Mini-Card 4W_T2 4-Wire Touch Connector socket 5W_T1 5-Wire Touch Connector...
- Page 6 Jumpers & Connectors Locations 4W_T1 COM5 SATA1 LVDS1 12VIN1 4W_T2 JVLCD1 JTS1 SAPO1 INV1 LPT1 T_LED1 LVDS1 JPWR1 EATX1 KBMS1 5W_T1 IDE1 SMBUS1 USB3 AUDIO1 DIO1 JNAND1 JFRT1 JBAT1 SPDIF1 FAN1 PCI1 4W_T3 JRS3 JRS4 COM1 CON3 CON4 VGA1 COM2 COM3 COM4 USB1...
-
Page 7: Jumper Settings
Jumpers Jumper Settings J2, J3: COM3 Port RS-232/422/485 Selection The jumper is “short” (closed) when the jumper cap is placed on pins. If not, that means the jumper is “open.” Connector type: 2.00mm pitch 2x3-pin headers. Description Pin 1-2 short Pin 2-3 short Sets Pin-1 to DSR# (Default) Pin short... - Page 8 Connector type: 2.54mm pitch 1x3-pin headers. Mode +12V Keep CMOS data (Default) FAN_Detect Clear CMOS data JNAND1: NAND Drive Setting This jumper is only available for ITX-i2705D. The default is “Short” (Master). Connector type: 2.54mm pitch 1x3-pin headers. Mode Short Master (Default) Open...
- Page 9 4W_T2: 4-Wire Touch Screen Connector JFRT1: Switches and Indicators Connector type: 2.54mm pitch 1x4-pin headers Once connected with case-mounted buttons, these connectors will act as LED indicators and switches for Description the computer status and activity. Connector type: 2.00mm pitch 1x8-pin box wafer connector Description PLED+ PLED-...
- Page 10 INV1: LCD Inverter Connector TV1: TV-out Connector Connector type: 2.00mm pitch 1x5 box wafer Connector type: 2.00mm pitch 1x6-pin box wafer connector. connector Description Composite Video +12V CVBS Unused Backlight on/off Unused Brightness control S-Video Unused Luminance AC1: HD AUDIO daughter board Connector Chrominance Connector type: 2.00mm pitch 1x9 box wafer connector.
- Page 11 SATA1: Serial ATA Connectors KBMS1: Keyboard & Mouse Connector High speed transfer rates (150MB/s). Connector type: 2.0mm pitch 1x6-pin box wafer connector. Description KB_DATA COM5: Serial Ports Connector This connector includes two RS-232 serial ports. MS_DATA Connector type: 2.00mm pitch 2x10-pin box headers. KB_CLK PS2_VCC Port...
- Page 12 MC1: Mini-Card Socket VGA1: Analog RGB Connector Connector type: VGA: D-Sub 15-pin female Mini-Card Pin Desc. Pin Desc. Desc. Socket GREEN VDDAT BLUE HSYNC COM1: Serial Port Connector VSYNC Connector type: 2.00mm pitch 2x5-pin box headers. VDCLK Pin Desc. Desc. DCD# DTR# USB1~2: Double Stacks USB Type A...
