Arbor Technology ITX-i9453 Quick Installation Manual

Quick Installation Guide

Version: 1.0
ITX-i9453
FORM FACTOR
Mini-ITX
MEMORY
DDR2 2GB
Expansion Bus
PCI-Express x 16
Mini PCI
Copyright © 2006 All Rights Reserved.

Technical Support

If you have any technical difficulites, please consult the user's manual first at:
ftp://ftp.arbor.com.tw/pub/manual
Please do not hesitate to call or e-mail our customer service when you still can
not find out the answer.
http://www.arbor.com.tw
E-mail: info@arbor.com.tw
Part Number: 4041945300100P
Specification

Processor

Support Socket 478 Intel® Core™ Duo processor
Chipset NB : Intel 945GME SB: Intel ICH7M

System Memory

Support Two 240-pin Dual channel DDR2 SDRAM DIMM Socket Up to 2GB
Intel 945GM integrated GMA (Graphic Media Accelerator) 950 Technology
VGA/LCD Controller
Support Dual Display, CRT, DVI, LVDS
Dual Intel 82573V 10/100/1000 Base-T Ethernet LAN

Ethernet

I/O Chips Winbond W83627HF x 1
Phoenix-Award BIOS version 6.0PG

BIOS

Support 4MB Flash ROM
Realtek ALC655 5.1 CH AC97 Codec
Audio
Supports MIC-In / Line-In / Line-out
Serial ATA II x 2 with 300MB/s transfer rate
IDE Interface ATA-100 x 1 channel
Compact Flash Disk X 1 share with IDE1 Slave (Support up to 4GB)
COM 1: RS-232
Two Serial Port
COM 2: RS232/422/485 Select
Parallel Port Support SPP / EPP / ECP mode
FDD / Parallel Port
(Share mode)
(Floppy only support 1 drive)
K/B and Mouse Support Standard PS/2 K/B and Mouse
Universal Serial Bus 8 x USB 2.0 Ports
Mini PCI Socket & 16X-PCI Express Slot

Expansion Interface

Watchdog Timer
1~255 Level (sec or min)
Chipset
Hardware Monitor
Integrated in W83627HF
Chipset
RTC Support Real Time Clock
ATX Power connector and 4-pin ATX12V connector

Power Connector

Operation Temp. 0ºC ~ 60ºC
Dimension (L x W): 170 x 170 mm (6.7" x 6.7")
Note:
1. LAN 1/LAN 2 Support boot from LAN function
2. CompactFlash Card share by IDE1 resources,can not hot swap
CPU CHIPSET
μFCPGA 478
Intel 945GME /
Core Duo
ICH7M
Processor
IDE I/O
1 x UDMA 100
USB/Serial/LPT
2xSATA
LAN AUDIO
Dual Intel
PCI-Express AC'97 Codec
Giga LAN
1
3

Packing List

Before you begin installing your single board, please make sure that the following
materials have been shipped:
1x ITX-i9453 Mainboard
1x I/O Bracket
1x CPU Cooler
1x CD-ROM (For Driver used)
1x Quick Installation Guide
1x Warranty Card
Optional
1 x Cable Kit (CBK-07-7453-00) contains the followings:
Ultra DMA100 IDE Flat cable x 1
USB cable, L=250 mm x 2
Serial ATA cable x 1
Print cable x 1
LPT to FDD cable x 1

Ordering Information

TM
ITX-i9453VL2G Intel Core Duo Mini-ITX M/B with CRT/LCD, Audio, SATA II,
Dual PCIe Giga LAN and 16X-PCI Express slot
Cable Kit CBK-07-7435-00
Jumper/Connector Quick Reference

Jumpers

Label Function
JBAT1 Clear CMOS
JPWR1 PS_ON Switch
JRS1 COM2 RS-232/422/485 Select
JV1 COM1 Power Source Special Support
JVLCD1 LVDS Panel Voltage Selects
JP1 Compact Flash Disk Mode Select

Connectors

U13 CPU Socket for Intel Core
DIMM1,DIMM2 240-pin DDR2 DIMM Socket
PCIE1 PCI Express X16 Interface Slot
MINIPCI1 Mini PCI Interface
KBM1 PS/2 Keyboard and Mouse
VGA1 CRT +DVI Display
INV1 LCD Inverter Connector
LVDS1 LVDS LCD Panel Connector
COM1 COM1+COM2 Serial Port
CON1 RS-422 / 485 Output
IR1 Infrared (IR) Connector
LAN1 Ethernet Connector (include USB1/2 Connector)
LAN2 Ethernet Connector (include USB3/4 Connector)
USB1 USB 7/8 Connector
USB2 USB 5/6 Connector
AUDIO1 Audio Interface Port
PW1 ATX Power Connector
ATX12V1 ATX12V Connector
CPUF1 CPU Fan Connector
SYSF1 System Fan Connector
JFRT1 Front Panel (Switches and Indicators)
DIO1 Digital I/O Connector
LPT1 LPT Share FDD Connector
IDE1 Primary IDE Connector
SATA1,2 Serial ATA 1/2 Connector
CFD1 Compact Flash Socket
2
TM
Duo Processor
4
