User Manual
Form Factor
Mini-ITX
I/O
SATA/ USB 2.0/ USB3.0/
♦ Technical Support
If you have any technical difficulties, please consult the user's manual first at:
ftp://ftp.arbor.com.tw/pub/manual
Contact our customer service at the following addresses if your problem persists.
http://www.arbor.com.tw
E-mail: info@arbor.com.tw
♦ Declaration of Conformity
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions : (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Copyright
All Rights Reserved.
®
ITX-i87H0
Mini-ITX Industrial Motherboard
CPU
Intel® 4th Generation
Core
Family
TM
processors
LAN
RTL8111G Gigabit
Ethernet controller
- 1 -
Quick Installation Guide
Video
HDMI/LVDS/DisplayPort
Audio
Realtek ALC662, Mic-in/
Line-out
4041870001100P
Version 1.0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Arbor Technology ITX-i87H0
Summary of Contents for Arbor Technology ITX-i87H0
- Page 1 ITX-i87H0 Mini-ITX Industrial Motherboard Quick Installation Guide Version 1.0 Form Factor Video Mini-ITX HDMI/LVDS/DisplayPort Intel® 4th Generation Core Family processors Audio SATA/ USB 2.0/ USB3.0/ RTL8111G Gigabit Realtek ALC662, Mic-in/ Ethernet controller Line-out ♦ Technical Support If you have any technical difficulties, please consult the user’s manual first at: ftp://ftp.arbor.com.tw/pub/manual...
-
Page 2: Packing List
Packing List Before you begin to install your single board, please make sure that the following materials have been shipped: 1 x ITX-i87H0 Mini-ITX industrial motherboard 1 x Driver CD 1 x Quick Installation Guide 1 x I/O bracket 1 x DC 2.5 Jack to 7.4 Plug Cable If any of the above items is damaged or missing, contact your vendor immediately. -
Page 3: The Installation Paths Of Cd Driver
The Installation Paths of CD Driver Windows 8 & 8.1 Driver Path \ITX-i87H0\Chipset\Win 8.1\32bit CHIPSET \ITX-i87H0\Chipset\Win 8.1\64bit \ITX-i87H0\\Graphic\Win 8.1\win32_1536b GRAPHIC \ITX-i87H0\Graphic\Win 8.1\Win64_153117 ETHERNET \ITX-i87H0\Ethernet\Win 8.1 \ITX-i87H0\AUDIO\Win 8.1\32bit AUDIO \ITX-i87H0\AUDIO\Win 8.1\64bit \ITX-i87H0\ME\Win 8\32bits_ME9.0_5M_V9.0.2.1345 \ITX-i87H0\ME\Win 8\64bits\MEI_Win8.1_5.0M_9.5.15.1730_PV \ITX-i87H0\CIR\Win 8 Windows 7 Driver Path... -
Page 4: Specifications
Specifications Form Factor Mini-ITX industrial motherboard Intel® 4th Generation Core Family processors in LGA1150 socket Chipset Intel® PCH H87 2 x 204-pin DDR3 SO-DIMM socket supporting System Memory 1600/1333 MHz SDRAM up to 16GB ® Graphic Chipset Integrated Intel Gen 7 Graphics 1 x HDMI_OUT port 1 x HDMI_IN port Graphic Interface... -
Page 5: Board Dimensions
Board Dimensions Unit:mm - 5 -... -
Page 6: Jumpers/Connectors Quick Reference
Jumpers/Connectors Quick Reference Jumpers Label Function ❶ LCD Resolution Selection LCD_SEL ❷ Clear CMOS Setting CLR_CMOS ❸ ME_UNLOCK ME unlock header Connectors Label Function Label Function ①SATA1,2 Serial ATA connectors USB3R1,2 USB 3.0 Connector ②SYS_FAN Fan Power Connector Displayport ③CPU_FAN CPU Fan Power Connector HDMI-OUT HDMI Output Connector... - Page 7 Jumpers & Connectors Locations MON_SW USB_CR_CAM DISP_BRT LVDS F_USB ITX-i87H0 LCD_SEL F_PANEL CPU_FAN SYS_FAN SODIMM1/2 SATA1/2 USB_TP SATA_PWR DMIC USB3F SPKR CLR_CMOS CASE F_AUDIO ME_UNLOCK DC_IN HDMI_IN HDMI_OUT USB3R1/2 LINEOUT - 7 -...
-
Page 8: Jumper Settings
Jumpers Connectors ①SATA1&2: Serial ATA Connectors Jumper Settings The jumper is “short” (closed) when the jumper cap is placed on pins. If not, that means the jumper is “open.” The pin assignments conform to the industry standard. Pin 1-2 short Pin 2-3 short Pin short Pin open... - Page 9 ⑥LVDS:LVDS Connector (40-Pin) Connector Type: 0.5mm pitch 40-pin coaxial connector Assignment Assignment ODD Lane3 + ODD Lane3 - Power +3.3V ODD Lane2 + ODD Lane2 - ODD Lane1 + ODD Lane1 - Dual Channels LVDS clock ODD Lane0 + Dual Channels LVDS clock ODD Lane0 - EVEN Lane3 + EVEN Lane3 -...
- Page 10 ⑦MON_SW: LVDS brightness switch ⑪F_USB: 10-pin USB 2.0 header supports card reader and cam- header era or other USB 2.0 devices Connector Type: 2.54mm pitch 1x2-pin headers. Connector Type: 2.54mm pitch 2x5-pin headers. Description Pin Description Pin Description LCD Backlight USB Port A (-) USB Port B (-) USB Port A (+)
- Page 11 ⑮⑯MIC&LINE OUT: Microphone&Line-out CASE: Chassis Intrusion detect header Connector Type: 2.54mm pitch 1x2-pin headers. The pin assignments conform to the industry Description standard. LINEOUT MIC Chassis cover is Short removed ⑰LAN: Ethernet Connectors Chassis cover is Open closed The pin assignments conform to the industry standard.
- Page 12 SATA_PWR: Serial ATA Power Connector USB_TP: 5-pin USB 2.0 header Connector Type: 2.54mm pitch 1x5-pin headers. The pin assignments conform to the industry Description standard. USB- USB3F: Front USB 3.0 header USB+ Connector Type: 2.00mm pitch 2x10-pin box wafer connector Pin Description Pin Description Power...
