Removing Packing Material and Making Internal Connections
3. Lift up, then remove the fluid module cover.
4. Remove tubes D and E.
5. Loosen the 6 fluid module retaining screws.
6
SediGraph III 5120 Installation
Tubes D and E
Retaining screw
Mar 2010
