The iBoot-G2+ Command Line Interf
The syntax of the CLI uses a basic S
either through the Telnet protocol, w
communications program like Hype
http://dataprobe.com/support/iboot.html.
8.1. CLI Access
Via Telnet
Open the Telnet client and connect to the IP address set for the iBoot.
Via USB
Open the console client and con
p arameters a re: 9600bps. 8 data bits. No parity. 1 Stop bit. No Flow Control. Once the connection is made
send Enter.
W hen connecti on is successful, the User> prompt is displayed. Enter user or admin and press Enter. The
prompt will change to Password>. Enter the admin or user password and press
to iBoot>. This indicates successful login. Enter commands as needed. When done, enter the logout
command.
8.2. iBoot-G2+ CLI Syntax
Command
Control Commands
set <main | exp1 | exp2> <on |
off | cycle>
get outlets
get status
V100915E

8. Command Line Interface

ace (CLI) provides a text based method for communicating with the iBoot.
et (change a variable) and Get (retrieve a variable). The CLI is accessed
hich requires a Telnet client program, or via USB which requires a serial
rterminal. Dataprobe also provides a simple terminal program (EZ Term) at
nect to the COM port assigned to the iBoot-G2+. The communications
Description
These commands are used to monitor and control the outlet.
This command controls the main outlet, Exp1 or Exp2
For Exp1 and Exp2; on = Closed , off = Open
This command returns the current status of the main and
exp ansion outlets. The response to this command is
determ ined by the expansion mode setting.
If iB
oot-Exp mode:
Main Out let: On
Exp 1: On L (L indicated Locked to Main)
Exp 2: Off
If Independent I/O mode:
Main Outlet: On
Exp1:
Input: Open
Output: Closed
Exp2:
Input: Open
Output: Open
iBoot-G2+
Enter. The prompt will change
Factory Default
Page 20
