Dataprobe iBoot-G2+ Manual page 14

7.3. Network Settings
IP Mode: Select Static to set th
the fields below, or DHCP to all
set the IP Address.
IP address: Enter a static IP address. This will be
automatically set if using DHCP
Subnet Mask: Enter the Subnet Mask. This will be
automatically set if using DHCP
Gateway: Enter the Gateway. This will be
automatically set if using DHCP
HTTP Port: This setting is used to allow access to
iBoot-G2+ on a port other than the Web standard Port
p ort numbe r when you enter iBoot's IP address into your browser. If the new port is 9105 then use the address
http://192.168.1.254:9105.
Telnet Port: This setting is used to allow access to the iBoot-G2+ via telnet by ports other than standard 23.
DxP Port: This setting is used to allow access to the iBoot-G2+ via Dataprobe Exchange Protocol (DxP) via
ports other than standard 9100.
Enable DxP Control: This setting enables external devices to control the iBoot-G2+ via DxP protocol.
E nable DxP Query:
p rotocol.
Note: All of the TCP/IP Settings require a re
button will appear at the bottom of the page.
rebooted. Reboot will not affect the power
Goodbye page is displayed with a link to re-login.
V100915E
e IP address using
ow a DHCP server to
This setting enables external devices to query the status of the iBoot-G2+ via DxP
iBoot-G2+
80. If the port is changed, you will need to identify the
boot of the iBoot-G2, after clicking Save. A Reboot
The new settings will not take effect until the unit is
position of the iBoot-G2. Upon Clicking Reboot, the
Page 14
