- Page 1 FACTORY AUTOMATION MANUAL ENI58PL-S***, ENI58PL-R*** Programming via IO-Link...
- Page 2 ENI58PL-S***, ENI58PL-R*** With regard to the supply of products, the current issue of the following document is ap- plicable: The General Terms of Delivery for Products and Services of the Electrical Indus- try, published by the Central Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its most recent version as well as the supplementary clause: "Expanded reservation of proprietorship"...
-
Page 3: Table Of Contents
ENI58PL-S***, ENI58PL-R*** Introduction................. 4 Content of this Document ..............4 Target Group, Personnel..............4 Symbols Used ..................5 Intended Use ..................5 General Safety Instructions ..............6 Declaration of Conformity ..............6 Product Description ..............7 Use and Application................7 Accessories .................. -
Page 4: Introduction
ENI58PL-S***, ENI58PL-R*** Introduction Introduction Content of this Document This document contains information required to use the product in the relevant phases of the product life cycle. This may include information on the following: Product identification Delivery, transport, and storage Mounting and installation Commissioning and operation Maintenance and repair Troubleshooting... -
Page 5: Symbols Used
IODD (IO Device Description) into an FDT frame program or by using the Pepperl+Fuchs SmartBridge® and a mobile device in conjunction with the SmartBridge® app via Bluetooth. We recommend using the "PACTware" software as an FDT... -
Page 6: General Safety Instructions
This product was developed and manufactured under observance of the applicable European standards and guidelines. Note! A Declaration of Conformity can be requested from the manufacturer. The product manufacturer, Pepperl+Fuchs GmbH, D-68307 Mannheim, has a certified quality assurance system that conforms to ISO 9001. ISO9001... -
Page 7: Product Description
Offline parameterization You can carry out offline parameterization using either an IO-Link master USB and an FDT frame application or using the Pepperl+Fuchs SmartBridge® and a mobile device in conjunction with the SmartBridge® app via Bluetooth. We recommend using the "PACTware" software as an FDT frame application and user interface. -
Page 8: Accessories
ENI58PL-S***, ENI58PL-R*** Product Description Accessories Various accessories are available. 2.2.1 Programming Aids for Use with the IO-Link Master USB Note! The simplest way to obtain the software products listed below is to download them from the www.pepperl-fuchs.com website on the product page for the relevant ENI58PL rotary encoder. -
Page 9: Connection Cable For Programming
ENI58PL-S***, ENI58PL-R*** Product Description 2.2.3 Connection Cable for Programming Depending on the connection type on the rotary encoder, the following adapter cables are available for connecting the rotary encoder to the IO-Link master: Connection type on the rotary encoder Adapter cable Connection type of the adapter cable M12, 5-pin V15S-G-0.5M-CGR-BD... -
Page 10: Installation
ENI58PL-S***, ENI58PL-R*** Installation Installation Instructions for Mechanical and Electrical Installation Note! More installation-relevant information on technical data, mechanical data, and available connection cables for the relevant incremental rotary encoder types "ENI58PL-S***" and "ENI58PL-R***" can be found in the corresponding datasheet. Please observe the following instructions to ensure safe operation of the incremental rotary encoder: Warning! - Page 11 Do not allow the rotary encoder to fall or expose it to strong vibrations. The rotary encoder is a precision instrument. Rotary encoders from Pepperl+Fuchs are robust; however, they should nevertheless be protected against damage in ambient conditions by taking appropriate protective measures.
-
Page 12: Connection For Io-Link Programming
ENI58PL-S***, ENI58PL-R*** Installation Connection for IO-Link Programming Connection for IO-Link programming via IO-Link master USB Connect the rotary encoder to the IO-Link master via a suitable 5-wire connection cable, depending on the connection type of the rotary encoder (according to the following table). Connection for IO-Link programming via IO-Link master USB M23 connector M23 connector... - Page 13 ENI58PL-S***, ENI58PL-R*** Installation Connection for IO-Link programming via SmartBridge® 24 V DC 24 V DC > 1A ENI58PL* Power Supply Bluetooth M12x1 M12x1 1. Connect the SmartBridge® to the rotary encoder using a suitable connection cable, depending on the connection type of the rotary encoder. 2.
-
Page 14: Connection For Normal Operation
ENI58PL-S***, ENI58PL-R*** Installation Connection for Normal Operation To use the rotary encoder in normal operation after programming, proceed as follows: Connect the rotary encoder to the higher-level control panel via a suitable connection cable, depending on the connection type of the rotary encoder (according to the following table). M12 x 1 connector M12 x 1 connector M23 connector plug,... -
Page 15: Commissioning
Commissioning with IO-Link in an FDT Environment Note! A 5-pin M12 cordset is necessary to connect the rotary encoder to the Pepperl+Fuchs IO-Link master. You can find suitable connection cables by visiting www.pepperl-fuchs.com and clicking on the product page for the relevant sensor. - Page 16 ENI58PL-S***, ENI58PL-R*** Commissioning Setting Up Sensor Communication Using PACTware (Step by Step) 1. Launch PACTware by double-clicking the PACTware icon. Figure 4.1 2. Click Project (1) at the top left. 3. Click Host PC (2), then click the right mouse button and select Add device (3). A window for selecting the device is displayed.
-
Page 17: Commissioning Using Io-Link And The Smartbridge
Commissioning using IO-Link and the SmartBridge Pepperl+Fuchs SmartBridge® simplifies setup and can be used to establish a connection to the rotary encoder. The combination of a mobile device, the SmartBridge® app, and the IODD make programming easy. - Page 18 ENI58PL-S***, ENI58PL-R*** Commissioning Figure 4.4 5. Open the SmartBridge® app and select the App Settings menu (1) using the corresponding menu option. Figure 4.5 6. Select Load custom IODD/GDD (2) to load first the IODD and then the GDD into the app in 2 separate steps.
- Page 19 ENI58PL-S***, ENI58PL-R*** Commissioning Figure 4.6 7. Tap + (3) to add the IODD and the GDD. First, select Add IODD... (4), and then select Add GDD... (5). If the files were implemented successfully, they will be displayed in the menu under Local IODD and Local GDD.
- Page 20 ENI58PL-S***, ENI58PL-R*** Commissioning SmartBridge® Authentication When the mobile device is initially connected with the SmartBridge interface, an authentication process first takes place between the communication partners. For this, each SmartBridge interface has a unique device key. The device key is located on the back of the SmartBridge interface in the form of a QR code and as text with the name "Key."...
-
Page 21: Io-Link Programming
ENI58PL-S***, ENI58PL-R*** Commissioning Figure 4.8 3. Select "SPECIALIST" as the user role to be able to use the entire range of programming features. If the authentication was successful and the rotary encoder has been detected, the app will switch to "Graphical View" and display the various programming options. -
Page 22: Io-Link Programming In The Pactware Fdt Environment
ENI58PL-S***, ENI58PL-R*** IO-Link Programming IO-Link Programming IO-Link Programming in the PACTware FDT Environment Overview The rotary encoder parameters are different for each device. A standardized description of these parameters can be found in the IO Device Description (IODD). The IODD can be imported into various engineering tools from different system providers, providing they support IODD. - Page 23 ENI58PL-S***, ENI58PL-R*** IO-Link Programming After parameterization, you must save the new configuration of the parameters in the non- volatile memory of the rotary encoder. Programming the rotary encoder 1. Set the required parameters for the Operation Mode Configuration and the Output Configu- ration.
-
Page 24: Io-Link Programming Using The Smartbridge
ENI58PL-S***, ENI58PL-R*** IO-Link Programming IO-Link Programming using the SmartBridge® Graphical View in the SmartBridge® app Figure 5.3 The menu can be used to program the rotary encoder for your application. The following parameters are adjustable: Resolution as a pulse count from 1 to 16384 Clockwise/counterclockwise direction of rotation Output configuration as a TTL or HTL signal level... - Page 25 ENI58PL-S***, ENI58PL-R*** IO-Link Programming As your settings are transferred to the device during live operation, you do not need to save your programming separately. Programming the rotary encoder Edit the relevant parameters. As your settings are transferred directly to the device during live operation, you do not need to save your programming separately.
-
Page 26: Troubleshooting
If none of the information provided in the checklist solves the problem, you can contact Pepperl+Fuchs via your sales office with any queries. Have details of the model number and firmware version of the sensor ready if possible. - Page 27 Twinsburg, Ohio 44087 · USA Tel. +1 330 4253555 E-mail: sales@us.pepperl-fuchs.com Asia Pacific Headquarters Pepperl+Fuchs Pte Ltd. Company Registration No. 199003130E Singapore 139942 Tel. +65 67799091 E-mail: sales@sg.pepperl-fuchs.com www.pepperl-fuchs.com Subject to modifications / DOCT-6268A Copyright PEPPERL+FUCHS • Printed in Germany 04/2019...
